NSK Small Tapered Roller Bearings , 40mm Single Row Tapered Roller Bearings
NSK Small Tapered Roller Bearings , 40mm Single Row Tapered Roller Bearings
Specifications
Brand Name :
NSK
Model Number :
30208
Place of Origin :
Japan
MOQ :
1pc
Price :
USD 0.1-1000/pc
Payment Terms :
TT, Western Union, MoneyGram,
Supply Ability :
10000pcs/month
Packaging Details :
Industrial packaging: plastic bag + kraft paper + carton or wooden ; plastic tube + carton
Type :
Single Row Tapered Roller Bearings
Bore Size :
40mm
Precision Rating :
P0 P6 P5 P4 P2
Vibration :
Z1V1 Z2V2 Z3V3 Z4V4
Description

Taper Roller Bearing Single Row 30208, 40mm Bore

Single Row Tapered Roller Bearings

Single Row Tapered Roller Bearings adopts CAD design and adopts advanced processing equipment and manufacturing processes including intermediate frequency hot forging and expansion forging, numerical control multi-knife, and profiling turning, heat treatment for protection atmosphere, numerical control grinding, and automatic grinding processing line production; the detection means are complete. Dynamic and non-destructive testing of the product's shape profile, roundness, roughness, vibration, noise, cracks, life, etc., and the effective operation of the TS16949:2002 and ISO9001:2000 quality systems ensure that the entire process quality is controlled.

Our Services

1. OEM &ODM service

2. We promise to reply your inquiry in 24 hours.
3. Complete product information will be offered
4. Free sample will be sent if you need .
5. Any other reasonable requirements as per requested

During production ,we provide:


1. Schedule of production
2 Mass production picture will offered
3. Any other reasonable requirements as per requested

Main purpose

Single Row Tapered Roller Bearings are widely used in automobiles, construction machinery, machine tools and general machinery industries, the company adhering to the "customer focus as the focus" to "pay attention to the process, strive for excellence" method, "to meet customers, mutual benefit and win-win" as the goal, established a perfect Quality Management System and Resource Management System (ERP).

Description
All types tapered roller bearings
Structure
Single Row Tapered Roller Bearings
Brand name
As the customer's requirement
Quality standard
ISO9001:2008
Services
OEM Based on your Aboriginal
Delivery time
5-20 days
Bearing package
Box ,carton ,pallet
Payment term
L/C ,T/T
Species
All models
Material
Chromium steel (main), carbon steel, stainless steel, ceramic
30000 series
30202,30203,30205,30206,30207,30302,30303,30305,30308,30352 ect
31000 series
31305,31306,31307,31308,31310,31311,31312,31313,31314,31319 ect
32000 series
32204,32204,32206,32209,32210,32303,32304,32305,32306,32334 ect
33000 Series
33205,33206,33207,33209,33210,33217,33108,33109,33110,33118 ect


Products Show:

NSK Small Tapered Roller Bearings , 40mm Single Row Tapered Roller Bearings


Specification:
NSK Small Tapered Roller Bearings , 40mm Single Row Tapered Roller Bearings

Bearing No. Dimensions (mm) Load Rating (KN) Mass
d D T B C R
mIn		 r
min		 C C0 kg
30202 15 35 11.75 11 10 0.6 0.6 15.0 14.3 0.053
30203 17 40 13.25 12 11 1.0 1.0 20.7 21.9 0.082
30204 20 47 15.25 14 12 1.0 1.0 28.2 30.6 0.128
30205 25 52 16.25 15 13 1.0 1.0 32.2 37.0 0.153
30206 30 62 17.25 16 14 1.0 1.0 43.3 50.5 0.231
30207 35 72 18.25 17 15 1.5 1.5 54.2 63.5 0.332
30208 40 80 19.75 18 16 1.5 1.5 63.0 74.0 0.417
30209 45 85 20.75 19 16 1.5 1.5 67.9 83.6 0.473
30210 50 90 21.75 20 17 1.5 1.5 73.3 92.1 0.529
30211 55 100 22.75 21 18 2.0 1.5 90.8 113.7 0.715
30212 60 110 23.75 22 19 2.0 1.5 103.3 130.0 0.905
30213 65 120 24.75 23 20 2.0 1.5 120.6 152.6 1.130
30214 70 125 26.25 24 21 2.0 1.5 132.0 173.0 1.238
30215 75 130 27.25 25 22 2.0 1.5 138.4 185.4 1.360
30216 80 140 28.25 26 22 2.5 2.0 160.4 212.8 1.680
30217 85 150 30.50 28 24 2.5 2.0 177.6 236.8 2.060
30218 90 160 32.50 30 26 2.5 2.0 200.1 269.6 2.560
30219 95 170 34.50 32 27 3.0 2.5 226.6 309.0 3.060
30220 100 180 37.00 34 29 3.0 2.5 253.9 350.3 3.740
30221 105 190 39.00 36 30 3.0 2.5 285.3 398.6 4.380
30222 110 200 41.00 38 32 3.0 2.5 314.9 443.6 5.233
