316L Stainless Steel Metal Pall Ring Random Tower Packing
316L Stainless Steel Metal Pall Ring Random Tower Packing
316L Stainless Steel Metal Pall Ring Random Tower Packing
316L Stainless Steel Metal Pall Ring Random Tower Packing
316L Stainless Steel Metal Pall Ring Random Tower Packing
316L Stainless Steel Metal Pall Ring Random Tower Packing
316L Stainless Steel Metal Pall Ring Random Tower Packing
316L Stainless Steel Metal Pall Ring Random Tower Packing
Specifications
Brand Name :
YUANHAI
Model Number :
YH-04
Certification :
ISO9001:2015
Place of Origin :
Hebei Province,China
MOQ :
5 cubic meters
Price :
USD280-1500/Cubic Meter
Payment Terms :
L/C,T/T
Supply Ability :
500 Cubic Meter/Cubic Meters per Month
Delivery Time :
5-8 work days
Packaging Details :
wooden case or customized
Material :
SS304,316,Stainless Steel,304L
Application :
tower packing,Industry,scrubbing
Shape :
Ring,Round,cylindrical,Cylindrical with teeth
Product name :
316L Metal Pall Ring Random Tower Packing,Metal Random Packing
Color :
the true color,Gray stainless steel metallic pall ring
Package :
Plastic Bag,Carton,Jumbo Bag
Sample :
Free sample
Keywords :
so2 absorption metal pall ring,Metal raschig ring
Description
High Surface Area Metal Tower Packing Round Corrosion Resistant For Tower Efficiency
Product Attributes
Attribute Value
Material SS304, 316, Stainless Steel, 304L
Application Tower packing, Industry, Scrubbing
Shape Ring, Round, Cylindrical, Cylindrical with teeth
Product name 316L Metal Pall Ring Random Tower Packing, Metal Random Packing
Color True color, Gray stainless steel metallic pall ring
Package Plastic Bag, Carton, Jumbo Bag
Sample Free sample
Keywords SO2 absorption metal pall ring, Metal raschig ring
Product Description

Our Metal Random Packing represents the industry benchmark for high-performance tower internals, engineered to maximize mass transfer efficiency in the most demanding separation processes. Utilizing precision-formed geometric configurations and premium corrosion-resistant alloys, this packing delivers superior vapor-liquid contact while minimizing energy consumption across distillation, absorption, and stripping applications.

Key Features
  • High Efficiency Mass Transfer - Optimized geometry enhances vapor-liquid mixing with large surface area (100-500 m²/m³) and low HETP (0.4-1.0m)
  • Corrosion & Temperature Resistance - 316L SS for acidic/chloride environments, stable from cryogenic to high-temperature processes
  • Cost & Energy Savings - 30-50% lower pressure drop vs. trays, long service life (10+ years), easy to install and maintain
Technical Specifications
Parameter Specification
Material Options 304SS, 316L SS, Carbon Steel, Monel, Titanium
Packing Types Pall Rings, Raschig Rings, CMR, IMTP
Surface Area 100-500 m²/m³ (varies by type)
Void Fraction 90-98% (optimized for flow efficiency)
Pressure Drop 20-100 Pa/m (lower than trays)
HETP 0.4-1.0m (depends on system conditions)
Capacity (Cₛ) 0.03-0.10 m/s
Operating Temp. -200°C to +550°C (material-dependent)
Certifications ISO 9001
Applications
Petrochemical Processing:
  • Crude oil atmospheric/vacuum distillation
  • Aromatics (BTX) separation columns
  • Olefin purification systems
  • Solvent recovery units
Gas Treatment:
  • Amine contactors for acid gas removal
  • Glycol dehydration towers
  • LNG purification trains
  • CO₂ capture absorption columns
Specialty Chemical:
  • High-purity pharmaceutical distillation
  • Electronic-grade chemical production
  • Fine chemical separation processes
Manufacturing Process
  • Material Preparation: Vacuum arc remelting (VAR), cold rolling to precise thickness tolerances (±0.02mm), ultrasonic cleaning and pickling
  • Precision Forming: CNC-controlled stamping, micro-perforation (0.5-3mm holes), edge conditioning
  • Surface Enhancement: Electrochemical polishing (Ra ≤ 0.4μm), optional specialty coatings, passivation per ASTM A967
  • Quality Assurance: 3D optical scanning, destructive testing, salt spray testing (2000+ hours), cleanroom packaging
Why Choose Our Metal Random Packing?
  • 10+ years of mass transfer expertise
  • Proprietary geometric designs
  • Advanced materials engineering
  • Complete technical support
  • Global project experience
Request samples with your operating parameters for a free efficiency analysis!
