Specifications
Brand Name :
YUANHAI
Model Number :
YH-G01
Certification :
ISO9001
Place of Origin :
HEBEI, CHINA
MOQ :
50m²
Price :
USD0.6-1.3/Square Meter
Payment Terms :
T/T
Supply Ability :
5000m² per month
Delivery Time :
10 days
Packaging Details :
According to customers' requirement
Product name :
Gabion Wire Mesh
Keyword :
Gabion Box
Material :
Galvanized Iron Wire
Hole shape :
Hexagonal
Wire diameter :
2.0-4.0mm
Application :
slope protection
Aperture :
80*100mm,10x12cm,5/8",6*8cm,8x10cm
Surface treatment :
Hot-dipped,Hot Dipped Galvanized PVC coated
Color :
green,black,gray
Width :
0.5-2m
Length :
1-30M,10m-200m
Sample :
free sample
Packing :
Pallet,Bundle,Water-proof Paper
Feature :
Simple construction,good permeability,corrosion resistance etc.
Description

PVC / Hot-dip Galvanized Iron Wire Gabion Wire Mesh For Slope Protection



Gabion Wire Mesh Description


Gabion, also known as gabion mesh, gabion cage, ecological grid, is an engineering structure woven from low-carbon steel wire or polymer wire.

Usually, these wires are galvanized to enhance their corrosion resistance. Gabion is mainly used in civil engineering and water conservancy projects, and has many uses and advantages.
River revetment metal cage, also known as gabion mesh, heavy hexagonal mesh, stone cage mesh, etc., is made of metal wire woven hexagonal mesh made of cage. These cages are mainly used in river revetment and other water conservancy projects to prevent soil erosion and stabilize river beds and banks.

Gabion Wire Mesh Specification


Surface Treatment Mesh Size Mesh Wire(mm) Selvedge Wire(mm) Lacing Wire(mm)

Heavy Hot dipped
Galvanized or
Golfan galvanized
and PVC coating		 60*80 2.0mm/3.0mm
2.2mm/3.2mm		 2.8mm/3.8mm
3.0mm/4.0mm

1.8mm/2.8mm
2.0mm/3.0mm
80*100
80*120		 2.2mm/3.2mm
2.5mm/3.5mm
2.7mm/3.7mm		 3.0mm/4.0mm
3.2mm/4.2mm
3.4mm/4.4mm
2.2mm/3.2mm
100*120
100*150		 2.2mm/3.2mm
2.5mm/3.5mm
2.7mm/3.7mm		 3.0mm/4.0mm
3.2mm/4.2mm
3.4mm/4.4mm
2.2mm/3.2mm

120*150		 2.2mm/3.2mm
2.5mm/3.5mm
2.7mm/3.7mm		 3.0mm/4.0mm
3.2mm/4.2mm
3.4mm/4.4mm
2.2mm/3.2mm


Gabion Wire Mesh Application


1.River management: used for river bank and bottom protection to prevent water erosion and protect the stability of riverbed and riverbank.

2.Slope protection: used for slope protection, slope support, and prevention of landslides and mud-rock flows.
3.Road construction: used for roadbed reinforcement of highways and railways to prevent roadbed deformation.
4.Coastal protection: used for coast and dock revetment projects to prevent wave erosion.
5.Bridge protection: used for the protection of bridge piers and abutments to prevent water erosion of bridge foundations.


Gabion Wire Mesh Characteristics


1.Good water permeability
The gabion mesh structure has good water permeability, which helps the natural exchange of groundwater
and avoids soil loss caused by water flow pressure.
2.Strong flexibility
The mesh structure of the gabion mesh can adapt to terrain changes and external environmental changes such as
earthquakes and settlements.
3.Good environmental protection
There are gaps between the stones filled inside the gabion mesh, which provides conditions for the growth of vegetation and has good ecological benefits.
4.Convenient construction
The gabion mesh can be prefabricated in the factory and filled with stones and installed after being transported to the site, with fast construction speed and short construction period.

Gabion Wire Mesh Advantages

Ecological environmental protection, integrity, softness, durability, water permeability, low cost, good wave performance. These advantages make the river revetment metal cage an ideal choice to protect the riverbed and riverbank.

Gabion Wire Mesh Process
PVC / Hot-dip Galvanized Iron Wire Gabion Wire Mesh For Slope ProtectionPVC / Hot-dip Galvanized Iron Wire Gabion Wire Mesh For Slope ProtectionPVC / Hot-dip Galvanized Iron Wire Gabion Wire Mesh For Slope Protection
