Heavy Duty Anti Slip Galvanized Walkway Grating For Industrial Flooring
Heavy Duty Anti Slip Galvanized Walkway Grating For Industrial Flooring
Heavy Duty Anti Slip Galvanized Walkway Grating For Industrial Flooring
Heavy Duty Anti Slip Galvanized Walkway Grating For Industrial Flooring
Specifications
Brand Name :
YUANHAI
Model Number :
YH-G1
Certification :
ISO9001
Place of Origin :
CHINA
MOQ :
50Pcs
Price :
USD5-26/pc
Payment Terms :
T/T,L/C
Supply Ability :
5000Pcs Per Month
Delivery Time :
5-10days
Packaging Details :
1.normally packed in pilling up ways with two pieces of square wood on both upperand bottom sides. 2.acccording to customer's requirements.
Sample :
Free
Keyw Word :
Steel Walkway Grating
Bearing Bar Pitch :
15,20,25,30,33,35,38,40,50,60,80mm
Weld Way :
Welded , Pressure-locked , Swage Locked
Type :
flat steel bar ,serrated steel bar
Cross Bar Spacing :
100mm
Installation Method :
Welded
Bearing Bar Size :
25mm x 3mm
Weld Type :
Pressure Welded
Payment Options :
T/T, L/C
Description
Heavy Duty Anti Slip Galvanized Walkway Grating For Industrial Flooring
Product Attributes
Attribute Value
Sample Free
Keyw Word Steel Walkway Grating
Bearing Bar Pitch 15,20,25,30,33,35,38,40,50,60,80mm
Weld Way Welded, Pressure-locked, Swage Locked
Type flat steel bar, serrated steel bar
Cross Bar Spacing 100mm
Installation Method Welded
Bearing Bar Size 25mm x 3mm
Weld Type Pressure Welded
Payment Options T/T, L/C
Product Description
Heavy Duty Steel Walkway Grating - Export Quality Anti-Slip Industrial Flooring Global Supply
Product Introduction
Engineered for demanding industrial environments worldwide, our Heavy Duty Steel Walkway Grating delivers unmatched safety and durability. Featuring robotic-welded construction and triple-layer corrosion protection, this grating withstands extreme loads (up to 5,000 kg/m²) while providing superior slip resistance. Pre-fabricated modular panels enable rapid global deployment - from offshore oil rigs to chemical plants.
Core Technical Specifications
Parameter Standard Premium
Material Q235 Carbon Steel 316 Stainless Steel
Coating 300g/m² Hot-Dip Galvanized PVC + Galvanized Dual Layer
Load Capacity 3,000 kg/m² 5,000 kg/m²
Slip Rating R10 (DIN 51130) R13 (High Risk)
Panel Size 1m × 3m Custom ≤6m Length
Mesh Options 30×3, 40×4, 50×5 mm Serrated Surface
Certifications ASTM A36, ISO 9001 CE, OSHA, EN 1090
5 Competitive Advantages
1. Safety First
  • Serrated tooth surface (R13 rating) for oil/wet conditions
  • Integrated drainage (70% open area) prevents liquid pooling
  • OSHA/EN ISO 14122 compliant fall protection
2. Corrosion Defense
  • Galvanized + PVC coating survives 5,000hr salt spray (ASTM B117)
  • 316SS option for acid/alkali environments (pH 1-14)
3. Heavy Load Mastery
  • Reinforced bearing bars (5-8mm thickness)
  • 0.5° maximum deflection under full load
4. Global Logistics Ready
  • Nested packaging - 80% space saving vs competitors
  • Pre-loaded containers (20GP: 400m² / 40HQ: 900m²)
5. Installation Efficiency
  • Clip-on system - 50m²/hour installation speed
  • Laser-cut notches for pipe/cable penetrations
Industry Applications
Sector Use Case Recommended Type
Oil & Gas Offshore drilling platforms 316SS Serrated R13
Chemicals Acid storage walkways PVC-Coated Galvanized
Power Plants Turbine access passages Heavy Duty 50×5mm Mesh
Water Treatment Sewage plant catwalks Hot-Dip Galvanized
Mining Conveyor maintenance paths Carbon Steel + Grit Coat
Manufacturing Excellence
  • Precision Cutting - CNC plasma cutting (±0.5mm tolerance)
  • Surface Tech - 7-stage galvanizing line (450°C immersion), Electrostatic PVC powder coating
  • Quality Control - 3D scanning for flatness, Load simulation testing
Global Supply Advantages
  • Lead Time: 15 days (standard) / 30 days (custom)
  • Shipping: FOB/CIF with INCOTERMS 2020
FAQ
Q: How to calculate required load capacity?
A: Use formula: Live Load (kg/m²) × Safety Factor 1.5. We provide free engineering support.
Q: Saltwater resistance comparison?
Material Coastal Lifespan Maintenance Cycle
Standard Galvanized 15 years Annual inspection
PVC-Coated 25+ years Biannual inspection
316SS 40+ years Minimal
Q: Minimum order for OEM?
A: 200m² with custom branding (laser-etched logos available).
Q: Warranty against corrosion?
A: 10-year guarantee (excluding mechanical damage).
