Modular Stainless Steel Wire Mesh Filters for Food and Pharma

Product Introduction

These Modular Stainless Steel Wire Mesh Filters are built for high-throughput food, beverage and pharmaceutical lines that require hygienic, reusable filtration with predictable performance. The modular approach (flat panels, pleated cartridges or stackable discs) lets you mix coarse pre-screens with fine Dutch-weave polishing layers in one assembly — reducing pressure drop while achieving required retention classes.

Why stainless wire mesh
Stainless media resists thermal and chemical stress from CIP/SIP routines and cleaning chemistries; electropolished finishes reduce biofilm risk and simplify validation. For fine liquid polishing and oil/water separations, Dutch-weave constructions (fine weft, coarser warp) offer tight cut sizes with reasonable permeability — the preferred choice where micron-level control is needed without sintered complexity.

Product Specification Sheet

Configurations & performance
Standard building blocks include: single- or multi-layer woven cloth, pleated cartridges to multiply media area in compact housings, and welded/framed panels for large inline strainers. Pleated stainless cartridges give long service life and easy onsite cleaning (backflush/solvent/ultrasonic), making them economical for reusable OEM and rental supply models. Typical initial ΔP and beta-ratio data are supplied per configuration to aid system selection.

Applications
Common applications: juice & beverage clarification, pharma API protection, CIP return screens, hydraulic oil pre-filtration, gas/liquid coalescing pre-filters and membrane pre-treatment.Provide ready OEM options, sample runs and small MOQs — useful for qualification runs before scaling.

Quality, testing & service
We supply material certificates (MTR), dimensional inspection reports, and optional particle retention testing (retention curves / βx). For sanitary lines we recommend electropolishing, traceable batch labels and validated CIP recipes; for high-temp/pressure industrial lines choose appropriate alloy (e.g., 316L or 904L) and welded end-fittings.
