50-1000mm Width Steel Galvanized Cable Tray Customizable Size Outdoor Cable Tray
50-1000mm Width Steel Galvanized Cable Tray Customizable Size Outdoor Cable Tray
50-1000mm Width Steel Galvanized Cable Tray Customizable Size Outdoor Cable Tray
50-1000mm Width Steel Galvanized Cable Tray Customizable Size Outdoor Cable Tray
50-1000mm Width Steel Galvanized Cable Tray Customizable Size Outdoor Cable Tray
50-1000mm Width Steel Galvanized Cable Tray Customizable Size Outdoor Cable Tray
Specifications
Certification :
ISO9001
Place of Origin :
Langfang, Hebei, China
Payment Terms :
T/T, PayPal, Xtransfer
Delivery Time :
Delivery within 15-30 days
Type :
Ventilated or Perforated Trough
Material :
Hot-dip Galvanized
Width :
50-1000mm etc.
Application :
Network, Industrial, Construction, managing cables, cable support, cable laying, cable wiring
Shape :
Rectangle
Feature :
Beautiful, strong, anticorrosive and durable
Surface Finishing :
Hot-dip Galvanized, Coated with Anti-corrosion Paint, pre-galvanized
Side Rail Height :
100MM, 50MM
Thickness :
Customized
Color :
Silvery
MOQ :
1000 pieces
Packaging Details :
Wooden frame or cardboard box packaging, customizable
Supply Ability :
50000 pieces per day
Price :
CN¥32.15-42.86
Description

Cable Management System Cable Tray Galvanized Steel Customizable Size Outdoor Cable Tray

Product Description

Galvanized cable tray is a metal structural component used to support and fix cables and wires, with its surface treated with galvanizing. The galvanizing process is mainly used to prevent the bridge from rusting in humid and corrosive environments, thereby improving its durability and service life. The galvanized layer can effectively isolate the bridge substrate (such as steel) from contact with moisture and oxygen in the external environment, reducing the possibility of corrosion.

Features

1) The zinc coating has a thick thickness, a fine and uniform crystal structure, and no pores, thus exhibiting excellent corrosion resistance.
2) The purity of the zinc layer obtained through electroplating is high, and the corrosion rate in acid, alkali and other mist is slow, thus achieving effective protection of the steel substrate.
3) After chromic acid passivation treatment, the zinc coating can present various appearances such as white, colored, and military green, which are both beautiful and decorative.
4) Zinc coating has excellent ductility, so it can withstand forming processes such as cold stamping, rolling, and bending without damaging the coating.

Technical Parameters

Product type
Ladder Cable Tray/Channel Cable Tray/Perforated Cable Tray
Material
Hot-dip galvanized /stainless steel/ fireproof spray /aluminum alloy
Surface Treatment
Pre-Gal/Electro-Gal/Hot dipped galvanized/Powder coated/Polishing


Size
Width
50-1200mm
Side rail height
50-300mm
Length
2m-6m
Thickness
0.3-3.0mm


Steel Thickness (Recommend)
1.00mm - 50*25mm, 75*75mm
1.2mm-100*50mm, 150*100mm
1.5mm -200*100mm, 300*150mm, 400*150mm,500*150mm
2.0mm-600*200mm, 700*200mm
2.5mm-800*200mm
As customer requirements
Color
As customer requirements
Certification
ISO9001/CCC/CE/UL/CUL
Used
Wiring system,cable management,hoisting system,construction industry and so on
Loading Test
Our wire mesh cable tray meet the standards requirements of IEC61537 and NEMA VE-1
Non standard specifications are availabe according to customers' requirement

50-1000mm Width Steel Galvanized Cable Tray Customizable Size Outdoor Cable Tray

50-1000mm Width Steel Galvanized Cable Tray Customizable Size Outdoor Cable Tray

FAQ

Q1: Are you trading company or manufacturer ?

A1: We are factory.

Q2: How long is your delivery time?
A2: Generally it is 5-10 days if the goods are in stock. or it is 7-25 days if the goods are not in stock, it is according to quantity.
Q3: Do you provide samples ? is it free or extra ?
A3: Yes, we could offer the sample for free charge but do not pay the cost of freight.
Q4: What is your terms of payment ?
A4: Payment≤1000USD, 100% in advance. Payment≥1000USD, 30% T/T in advance ,balance before shippment.
