Dark Green Welded Wire Mesh Fencing Panels , Wire Panel Fence Peach Shape Post
Dark Green Welded Wire Mesh Fencing Panels , Wire Panel Fence Peach Shape Post
Dark Green Welded Wire Mesh Fencing Panels , Wire Panel Fence Peach Shape Post
Dark Green Welded Wire Mesh Fencing Panels , Wire Panel Fence Peach Shape Post
Dark Green Welded Wire Mesh Fencing Panels , Wire Panel Fence Peach Shape Post
Dark Green Welded Wire Mesh Fencing Panels , Wire Panel Fence Peach Shape Post
Dark Green Welded Wire Mesh Fencing Panels , Wire Panel Fence Peach Shape Post
Dark Green Welded Wire Mesh Fencing Panels , Wire Panel Fence Peach Shape Post
Specifications
Brand Name :
XINLONG
Model Number :
XLF-01
Certification :
ISO9001:2008
Place of Origin :
Anping, Hebei, China
MOQ :
1000
Price :
negotiate
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
1000 per week
Delivery Time :
8-15 Days
Packaging Details :
Pallet
Material :
Iron Wire
Wire Diameter :
5.0 mm
Mesh Size :
200 x 50 mm
Surface Treatment :
Powders Sparyed Coating
Color :
Dark Green
Width :
2.5 m
Height :
2.0 m
Suitable Post :
Peach Shape Post
Description

Powders Sprayed Coating Welded Wire Mesh Fence Panel With Bends

Characteristic:

  1. Extraordinary and fashionable design, convenient installation, high strong quality.
  2. The panels are welded by high quality cold drawn steel wire, after hot dipped galvanized or weld the panel with cold drawn wire directly, then to be galvanized.
  3. With the galvanized wire panels, it needs to inspect the zinc layer and others, only the eligible items could be coated.
  4. It includes the Powders sprayed coating or PVC/PE dipped coating. Then the products could last 15 years.
  5. The panels with bends can make it more stable and stronger.

Specification:

Wire Dia. Mesh Size Panel Width

Panel

Height

 Fold NO. Post’s height Post Model
Fix I Fix II Fix III

4.0mm

4.5mm

5.0mm

5.5mm

6.0mm

200*50mm

200*55mm

200*60mm

200*65mm

2.0m

2.255m

2.5m

3.0m

 0.635m 2 0.9 0.7 1.0

XLFP-01

XLFP-02

XLFP-05
0.835m 2 1.2 0.9 1.2
1.035m 2 1.4 1.1 1.4
1.235m 2 1.6 1.3 1.6
1.435m 2 1.8 1.5 ----
1.535m 3 1.9 1.6 ----
1.635m 3 2.0 1.7 ----
1.735m 3 2.2 1.8 ----
1.835m 3 2.3 1.9 ----
1.935m 3 2.4 2.0 ----
2.035m 4 2.5 2.1 ----
2.235m 4 2.8 2.3 ----
2.435m 4 3.0 2.5 ----

Surface Treatment Min. Max.
Electric Gal. 20g/m2 60g/m2
Hot dipped Gal. 35g/m2 700g/m2
Powders Sprayed coating 100microns 120microns
PVC/PE dipped coating 400microns 600microns

Range of application:

  1. Road and Transit ( Highway, Railway, Road, City Transit )
  2. Science Industry Zone ( Industry Zone, Sightseeing Zone, New pattern farm )
  3. Private grounds ( Courtyard, Villa )
  4. Public grounds ( Park, Zoo, Train or Bus Station, Lawn )

Design Advantage:

  1. Extraordinary and fashionable design, convenient installation.
  2. The fence panels are joined with post without any clamps, and it is easy and convenient.
  3. It could insert into the sew of concrete base of 40mm width.
  4. Usually there is the plastic caps on the top of the post.

Colors:

Every RAL color designed can be delivered, for example the colors corresponding to your corporate design.

  • Common colors:
  • Dark Green RAL6005
  • Pure White RAL9010
  • Stone Grey RAL7030
  • Jet Black RAL9005
  • Anthracite Grey RAL7016
  • Other RAL colors are available
