25mm 304 Distillation Tower Pall Ring Packing 0.5 Mm Thickness
25mm 304 Distillation Tower Pall Ring Packing 0.5 Mm Thickness
25mm 304 Distillation Tower Pall Ring Packing 0.5 Mm Thickness
25mm 304 Distillation Tower Pall Ring Packing 0.5 Mm Thickness
Specifications
Certification :
ISO9001
Place of Origin :
China
MOQ :
0.01 cubic meters
Price :
negociation
Payment Terms :
T/T
Supply Ability :
99 cubic meters per month
Delivery Time :
5-9 days
Packaging Details :
carton, bag, pallet
Product name :
Metal pall ring
size :
1 in / 25 mm
Material certificate :
Yes
wall thickness :
0.5 mm
data sheet :
available
OEM :
Yes
Material :
SS304
Application :
distillation tower packing
Sample :
free sample
Warranty :
lifetime online service
Description

25 Mm 304 Distillation Tower 0.5 Mm Thickness Metal Pall Ring

1. Metal Pall Ring Basic Info:

Metal pall rings have more than 50% higher capacity than raschig ring. The pressure drop is only half of the raschig ring. The relative efficiency is about 30% higher than that of raschig ring.

2. 25 mm Metal Pall Ring Specification:

25mm Pall Rings
Free Space (%) 94 25mm 304 Distillation Tower Pall Ring Packing 0.5 Mm Thickness
Specific Surface Area (m2/m3) 209
No. Per Unit Volume (m3 ) 49,500
Packing Factor (m-1) 176

Specific Weight (kg/m3) 322 – 644

Stainless Steel
Dimensions (mm) 25 x 25
Thickness (mm) 0.4 – 0.8

3. Metal Pall Ring is a new type of filler improved on Raschig ring.

Compared with the later, pall ring has improved the liquid distribution of filler layer greatly, with open windows on ring sidewall. Therefore it has productivity, low resistance, operating flexible and higher efficiency. Pall ring is widely applied to industry. It is still one of major annular fillers that has been adopted.

4. Metal Pall Ring Features:

Easily wettable

High resistance to fouling

High temperature endurable

High temperature applications

HIGH MECHANICAL STRENGTH

High capacity with low pressure drop

Mechanically robust, lesser probability of breakage

Good liquid/gas distribution and high mass transfer efficiency

5. Metal Pall Ring Production & Shipment

25mm 304 Distillation Tower Pall Ring Packing 0.5 Mm Thickness
25mm 304 Distillation Tower Pall Ring Packing 0.5 Mm Thickness
Welcome your inquiry with any questions!
