Welded Wire Mesh Gabion Box Stone Retaining Wall Panels Stone Basket Mesh For Sale
Welded Wire Mesh Gabion Box Stone Retaining Wall Panels Stone Basket Mesh For Sale
Specifications
Brand Name :
KN
Model Number :
KN-welded gabion
Certification :
CE ISO SGS COC PVOC
Place of Origin :
CN
MOQ :
100 pc
Price :
USD 45-55
Payment Terms :
L/C, T/T, Western Union, MoneyGram
Supply Ability :
500 pc per day
Delivery Time :
15 work days
Packaging Details :
pallet
Product Name :
Welded Wire Mesh Gabion Box Stone Retaining Wall Panels Stone Basket Mesh For Sale
Key Words :
Welded Gabion
Shape :
Rectangular
Length :
0.3m-2m
Gabion Box Width :
30cm
Zinc Coating :
220-300g/m2
Gabion Box Height :
30cm, 50cm, 80cm, 100cm
Material :
Galvanized Steel Wire
Edge Wire Diameter :
3.0-4.0mm
Installation :
Easy to assemble and disassemble
Description

Welded Wire Mesh Gabion Box Stone Retaining Wall Panels Stone Basket Mesh For Sale

Welded gabion is a rigid mesh box made from high-strength steel wire welded at each intersection. It offers superior load-bearing capacity and a clean, modern aesthetic compared to traditional woven gabions.

Key specifications include mesh size (e.g., 2"x4", 3"x3", 100x100mm), wire diameter (typically 2.7mm to 4.0mm), and coating (Zinc, Galfan, or PVC/PE). It's widely used for retaining walls, landscaping, erosion control, and architectural facades.



The welded gabion basket details:

A) Panel: high quality galvanized panel of 50*50 or 75*75 mesh size
B) Sprial wires: good quality for same wire diameter as panel
C) Stifferens :4-8 stifferens per gabion, to make sure the gabion is more strong

Type of welded Gabion Wire Gauge Diameter Mesh Size Gabion Size
Galvanized 3-5mm 50X50,75X75,50X100 2*1*1, 1*1*1,1*1*0.5,etc
PVC Coated 3.0/3.8mm 50X50,75X75,50X100 2*1*1, 1*1*1,2*1*0.5,etc
95% Zinc + 5% Al 3-5mm 50X100,75X75,100X100 1*1*0.5,2*1*1,1*1*0.3etc


The welded gabion basket connection details
1. U -clips
2. C-ring
3. Lacing wire connection
4. Hook connection

The sprial wires & hooks or stiffeners is most popular as it's more strong for usage

Welded gabion basket advantage:

  1. Exceptional structural strength with welded joints for superior load-bearing capacity, ideal for critical engineering applications.

  2. Clean, precise appearance offering modern aesthetics, suitable for architectural finishes that enhance project quality.

  3. Rapid installation with modular units, simply assembled on-site and filled with stone, saving significant labor and time.

  4. Excellent durability and corrosion resistance, featuring high-grade zinc, Galfan, or PVC coatings for extended service life.

  5. Eco-friendly and permeable design using natural stone fill, allowing groundwater flow and promoting vegetation growth.

Welded Wire Mesh Gabion Box Stone Retaining Wall Panels Stone Basket Mesh For Sale
