Heavy Duty Woven Gabion Baskets Hexagonal Stone Gabion Mesh Engineering Slope Stabilization Zinc Coated
Heavy Duty Woven Gabion Baskets Hexagonal Stone Gabion Mesh Engineering Slope Stabilization Zinc Coated
Specifications
Brand Name :
KN
Model Number :
KN-Woven Gabion Baskets
Certification :
CE ISO SGS COC PVOC
Place of Origin :
CN
MOQ :
100 pc
Price :
USD 12-17
Payment Terms :
L/C, T/T, Western Union, MoneyGram
Supply Ability :
500 pc per day
Delivery Time :
15 work days
Packaging Details :
pallet of Woven Gabion Baskets
Product Name :
Heavy Duty Gabion Basket Hydraulic Engineering Slope Stabilization Zinc Coated
Key Words :
Woven Gabion Baskets
Edge Wire :
3.4mm
Material :
Galvanized Steel Wire
Wire Diameter :
2.7mm WIRE
Zinc Coating :
≥240g/m²
Aperture :
100 x 80 PVC coated or galvanised wire mesh
Mesh Shape :
Hexagonal
Tensile Strength :
350-500N/mm²
Surface Treatment :
Hot-dip Galvanized, Electro Galvanized
Description

Heavy Duty Woven Gabion Baskets Hexagonal Stone Gabion Mesh Engineering Slope Stabilization Zinc Coated

Hexagonal Stone Gabion Mesh

manufactured from 8x10 double twisted hexagonal woven steel wire mesh, as per ASTM A975-97 Gabions are filled with stones at the project site to form flexible, permeable, monolithic structures such as retaining walls, channel linings, and weirs for erosion control projects.

Gabion walls PVC coating has a nominal thickness of 0.02 in. (0.50 mm). The Gabion is divided into cells by diaphragms positioned at approximately 3 ft (0.9m) centers. To reinforce the structure, all mesh panel edges are selvedged with a wire having a greater diameter. Gabions shall be manufactured and shipped with all components mechanically connected at the production facility.

All tests on wire must be performed prior to manufacturing the mesh. All wire should comply with ASTM A975-97, style 3 coating, Galfan and PVC coated steel wire. Wire used for the manufacture of Gabions and the lacing wire, shall have a maximum tensile strength of 75 000 psi (515 MPa) as per ASTM A856-03, soft temper steel.

Heavy Duty Woven Gabion Baskets Hexagonal Stone Gabion Mesh Engineering Slope Stabilization Zinc Coated

  • Materials: galvanized wires, Galfan wires, PVC coated wires.
  • Colors: any color is available upon your request.
  • Opening: 60 × 80 mm, 80 × 100 mm and other customized sizes.
  • Gabion sizes: 2 × 1 × 1 m, 1 × 1 × 1 m, 3 × 1 × 1 m and customized sizes.
  • Heavy Duty Woven Gabion Baskets Hexagonal Stone Gabion Mesh Engineering Slope Stabilization Zinc Coated

Customization Services

  • Sizes: 2x1x1m (standard) up to 6x2x1m (heavy-duty)
  • Wire Diameters: 2.2mm – 4.0mm (3.0mm recommended for high-load zones)
  • Colors: Metallic Silver (standard), Green/Black PVC coating (urban projects)
gabion specifications Mesh hole modle
8x10cm 6x8cm
Length(m) Width(m) Height(m) Galvanized or PVC coated Galvanized or PVC coated
Mesh diameter Zinc Mesh diameter Zinc
2 1 1 2.7mm >245g/m² 2.0mm >215g/m²
3 1 1 Side wire diameter Zinc Side wire diameter Zinc
4 1 1 3.4mm >265g/² 2.7mm >245g/m²
6 1 1 Binding wire diameter of 2.7m Binding wire diameter of 2.0m
