Easy Operate Fence Mesh Panel Welding Machine For 3mm - 6mm Wire Diameter
Easy Operate Fence Mesh Panel Welding Machine For 3mm - 6mm Wire Diameter
Easy Operate Fence Mesh Panel Welding Machine For 3mm - 6mm Wire Diameter
Easy Operate Fence Mesh Panel Welding Machine For 3mm - 6mm Wire Diameter
Specifications
Brand Name :
MLG
Model Number :
WHJ-2500
Certification :
CE
Place of Origin :
Hebei China
MOQ :
One set
Supply Ability :
4--5 sets per month
Delivery Time :
30 days after receiving deposit or L/C.
Packaging Details :
Wooden pallet and the plastic package in the container.The bracket and auxiliary equipments will be with plastic package, spare parts in carton box. The main m
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Width of mesh :
Max 2500mm
Mesh size :
50*50--200*200mm (adjustable)
name :
automatic wire mesh welding machine
Welding speed :
45--60 times per min
Current :
Max 350A
Control system :
Mitsubishi PLC
Dimension :
8.5m*3.2m*1.7m
Weight :
4.2T
Description

Full Automatic Best Price Fence Mesh Panel Welding machine for 3--6mm

Advantages

1. Safe and easy to operate
2. Inverter with adjustable frequency;
3. Energy saving 30%;
4. High speed and high productivity;
3. low noise;
4. low cost.

Product Description

1.Control system:Japan Panasonic intelligent PLC.
2.Touch screen: Weiview(Taiwan).
3.Low-voltage apparatus :Schneider(France). Variable-frequency drive:Delta(Taiwan)
4.Pneumatic components: Japan SMC,more stable.
5.Brake clutch motor connect the pricipal axis directely, stronger power.(Patent technology)
6.Cross wire feeding: Step hopper. Longitude wire feeding:Manually.
7.Mesh pulling:Panasonic(Japan) servo motor, great power and precision.
8.Transformer cooling:Water cooling,very efficient.

Raw matrial

Low-carbon wire,black wire,stainless wire, galvanized wire.

Technical Parameters
Model MLG-WHJ-2500 Welding electrodes 48pcs
Wire diameter 3mm-6mm Rated electrical power 85kva*6pcs
Longitude wire space 50mm-300mm Longitude wire feeding Pre-straightened &pre-cut
Cross wire space 25mm-300mm Cross wire feeding Pre-straightened &pre-cut
Width of mesh 2500mm Overall size 8.4M*3.1M*1.7M
Welding speed 45-75times/min Weight 4200kg

When the wire diameter is 2.5mm-4mm, the minimum longitude space is 50mm.
When the wire diameter is 4mm-6mm, the minimum longitude space is 100 mm.
