MSA021D RC 24GHz Presence and motion sensor with dry contact output
MSA021D RC 24GHz Presence and motion sensor with dry contact output
MSA021D RC 24GHz Presence and motion sensor with dry contact output
MSA021D RC 24GHz Presence and motion sensor with dry contact output
MSA021D RC 24GHz Presence and motion sensor with dry contact output
MSA021D RC 24GHz Presence and motion sensor with dry contact output
Specifications
Brand Name :
Merrytek
Model Number :
MSA021D RC
Certification :
CE
Place of Origin :
China
MOQ :
100pcs
Price :
Negotiation
Payment Terms :
T/T or Western Union or PayPal
Supply Ability :
10,000pcs per month
Delivery Time :
1, Sample and small order: Within 5 working days after receiving your payment. 2, Bulk order: 3-4 weeks after receiving deposit.
Packaging Details :
Color box + flat card + outer box (K=A)
Detecting Technology :
major motion / minor motion / Presence detecting
Working Mode :
Dry contact
Rated Voltage :
12-24V DC
Stand-by Power :
0.5W
Load Capacity :
36V 50mA max Resistive
Working Frequency :
24GHz -24.25GHz，ISM band
Max. mounting height :
2.5-4m
Warranty :
5 years
Description
MSA021D RC 24GHz Presence and Motion Sensor with Dry Contact Output
Product Overview

The MSA021D RC is a sophisticated 24GHz presence and motion sensor featuring dry contact output, designed for reliable detection in various industrial and commercial applications.

Key Features
  • Exclusive Merrytek Lifebeing Presence Detection
  • FMCW modulation technology for detecting micro movements from breathing
  • German RF technology with 5-year guarantee assurance
  • Accurate Presence/Absence Output
  • Daylight Sensor Available
  • NO/NC dry contact output available
  • 24GHz ISM Band Millimeter Wave Radar technology
  • Major/Minor/Micro Motion detection diameter: 6-8m Max
Technical Specifications
Input/Output
Input voltage 12-24V DC
Rated voltage 12/24V DC
Working Current @12Vdc: 50mA max
@24Vdc: 30mA max
Working Power ≤1W @24V DC
Output signal NO/NC dry contact (Factory setting is NO dry contact)
Load type Resistive (load voltage: Vdc≤36V, load current: 100mA max)
Sensor Parameters
Radar frequency 24GHz - 24.25GHz, ISM band
Transmitting Power 5mW Max.
Detection Area 0-5m
Hold Time 10s-30min (For better presence detection, hold time shall be set >30S)
Daylight Sensor threshold 5Lux-150Lux/Disable
QS1+100% detection range radius Major/minor/micro movement (3m height installation): 4.5±0.5m (based on 41㎡ open area test and might change due to different space)
Remote control Available
Mounting height 2.5-4.0m (typical value: 3m)
Detecting Angle 120°
Application Environment
Drill hole Φ65-70mm
Working Temperature 0℃...+50℃
Storage Temperature -25℃~+80℃ Humidity: ≤85% (non-condensation)
Certificate & Standards
Certificate RED
Environmental Requirement Compliant with RoHS
IP Rating IP20
Guarantee 5 year (only for product quality problem)
Note: "N/A" means not available.
Product Images
MSA021D RC 24GHz Presence and motion sensor with dry contact output MSA021D RC 24GHz Presence and motion sensor with dry contact output MSA021D RC 24GHz Presence and motion sensor with dry contact output MSA021D RC 24GHz Presence and motion sensor with dry contact output MSA021D RC 24GHz Presence and motion sensor with dry contact output MSA021D RC 24GHz Presence and motion sensor with dry contact output MSA021D RC 24GHz Presence and motion sensor with dry contact output MSA021D RC 24GHz Presence and motion sensor with dry contact output MSA021D RC 24GHz Presence and motion sensor with dry contact output MSA021D RC 24GHz Presence and motion sensor with dry contact output MSA021D RC 24GHz Presence and motion sensor with dry contact output
