Specifications
Model Number :
CEP-LCLC-L40B003M
Interface, connector A :
LC/UPC
Interface characteristics, connector A :
Duple x
Connector, Connector B :
LC/UPC
Interface characteristics, connector B :
Duple x
Sheath color :
Aqua Green
Total cores, number :
2
Brand Name :
Commscope
MOQ :
1Pcs
Price :
Negotiate
Packaging Details :
Box
Delivery Time :
Based on inventory
Payment Terms :
T/T
Supply Ability :
Supply by project/batch
Description

CommScope OM4 Duplex LC Fiber Patch Cable - High-Speed Data Center Solution

Premium Multimode Fiber Connectivity

Engineered for demanding network environments, this OM4 duplex LC fiber patch cable delivers exceptional performance for 40G/100G Ethernet applications. Featuring advanced bend-resistant technology and field-reversible connectors, this multimode fiber patch cord ensures reliable high-speed data transmission in modern data centers.

High Performance

Supports 40G/100G Ethernet with superior bandwidth capabilities

Flexible Polarity

Field-reversible LC duplex connectors for easy configuration

Product Specifications

Core Specifications

Product Model CEP1CLC140B Series
Fiber Type OM4 Multimode 50/125μm
Connector Type LC/UPC Duplex Both Ends
Cable Diameter 1.8mm LSZH Jacket

Performance Metrics

Attenuation @850nm ≤ 3.0 dB/km
Attenuation @1300nm ≤ 1.0 dB/km
Operating Temperature -10°C to +60°C

Technical Features

Advanced Construction

This multimode LC-LC patch cord features precision LC/UPC connectors with zirconia ceramic ferrules for optimal optical performance. The duplex zipcord design allows easy separation and routing in high-density patch panels.

Bend Resistance

Superior bend performance with attenuation change less than 0.10dB at 850nm when bent around 15mm radius. Maintains signal integrity in tight spaces common in modern data centers.

Applications & Deployment

Data Centers

Server to switch connections, cross-connects, and high-density patching

Enterprise Networks

Backbone connections, telecommunications infrastructure, and SAN

High-Speed Computing

40G/100G Ethernet, storage area networks, and HPC environments

Length Selection Guide

Model Number Length Color Code Typical Use Case Price Tier
CEP1CLC140B001M 1 meter Aqua Green Intra-rack connections $
CEP1CLC140B003M 3 meters Aqua Green Standard rack connections $$
CEP1CLC140B005M 5 meters Aqua Green Adjacent rack connections $$
CEP1CLC140B010M 10 meters Aqua Green Data center aisle crossing $$$
CEP1CLC140B020M 20 meters Aqua Green Long-distance runs $$$$

Quality & Compliance

ISO 9001:2015

Quality Management System Certified

RoHS Compliant

Restriction of Hazardous Substances

TIA/EIA-568-C.3

Commercial Building Standard

Frequently Asked Questions

What applications is this OM4 duplex LC patch cord best suited for?

This multimode fiber patch cord is ideal for 40G and 100G Ethernet applications in data centers, enterprise networks, storage area networks, and high-performance computing environments where high bandwidth and reliability are critical.

How does the bend-resistant fiber technology benefit installation?

The advanced bend-resistant fiber maintains signal integrity even when routed around tight corners or in high-density patch panels, reducing installation constraints and minimizing performance degradation in space-constrained environments.

What quality assurance measures are implemented?

Each multimode LC-LC fiber patch cord is 100% factory tested for insertion loss and continuity. Individual test data is provided with each cable, ensuring performance meets specified standards before shipment.

Can these patch cords be used in plenum spaces?

While the LSZH jacket provides enhanced safety characteristics, specific plenum ratings may vary by jurisdiction. Please consult local building codes and specifications for plenum space requirements in your area.

Ready to Enhance Your Network Infrastructure?

Experience the reliability and performance of CommScope OM4 fiber solutions
