Industrial Melamine Tableware Auto Weighing Machine PLC Intelligent Control
Industrial Melamine Tableware Auto Weighing Machine PLC Intelligent Control
Specifications
Brand Name :
DONGXIN
Model Number :
1350Lx800wx2350H
Certification :
SGS
Place of Origin :
CHINA
MOQ :
1
Price :
2815
Payment Terms :
L/C,T/T
Supply Ability :
20
Delivery Time :
7-10 DAYS
Packaging Details :
Plastic stretch wrap film
Voltage :
220V,380V,220V/50HZ,220V/380V;,60Hz
Automatic grade :
Automatic,Other,Semi-Automatic
Packaging type :
Bags,Pouch,Film,Foil,Barrel
Dimension(l*w*h) :
about 5*2*3.5m for the whole packing line,(L)4323X(W)2998X(H)3700mm,(L)172-(W)1030-(H)2254mm,(L)1217x(W)1015x(H)1343,1680(L)*1182(W)*1268(H)
Type :
Multi-Function Packaging Machine,Vertical form,Other,Filling Machine
Function :
Filling,Sealing,Wrapping,Labeling,Slitting
Warranty :
1 Year,12 Months,2 Years,1 year for automatic weighing and packing machine,one year
Packing speed :
5-60bags/min,5--60,10-20bags/min according to package capacity,10~50bags/min,20-40 bags/min
Material :
Stainless Steel/Painted Steel,304SS,SUS 304 Stainless Steel Material,Stainless Steel 304/316,Full stainless steel
Main function :
Weighting Packing,Filling Sealing Packing,Automatic Form,food automatic weighing and packaging machine,Weighing Forming Filling and Sealing
Description
Melamine Tableware Automatic Weight Machine
Automatic Weight Machine For Melamine Tableware
The Automatic Weighing Machine for Melamine Industry is an intelligent powder batching solution specifically engineered for melamine tableware manufacturing. This advanced equipment automates the precise measurement and distribution of melamine molding compound (A5 grade), urea moulding powder, and other thermosetting materials, ensuring consistent product quality and significantly reducing material waste and labor costs.
Industrial Melamine Tableware Auto Weighing Machine PLC Intelligent Control
Key Features & Technical Specifications
Precision Weighing Technology
  • Weighing Accuracy: Deviation tolerance ≤±2g
  • Weighing Range: 5g - 3000g per batch (adjustable for different product specifications)
  • Production Efficiency: ≤10 seconds per mold cycle (C/T)
  • Equipment Load Rate: Operational uptime ≥97%
Advanced Control Systems
  • Control Method: PLC intelligent control with touchscreen interface
  • Programming: Parameter modification on touch screen for easy operation
  • Communication Interface: Supports RS232/485 protocol
  • Motion Resolution: Conveying precision of 5mm
  • Repeated Positioning Accuracy: ≤±0.5mm for robotic handling
Industrial Melamine Tableware Auto Weighing Machine PLC Intelligent Control
Physical Specifications
Dimensions 1500×650×2200mm (L×W×H) / 1400×850×2400mm (alternative model)
Input Voltage AC 220V 50Hz or AC 380V 50Hz
Maximum Power 530W (220V) / 2.3KW (alternative configuration)
Air Source Pressure 0.4 - 0.6 MPa
Air Consumption 3.0 L/min
Hopper Capacity 25 - 40KG (single bag loading)
Machine Weight 200 - 280KG
Core Advantages for Melamine Manufacturers
Unmatched Weighing Precision
Utilizing world-renowned load cell sensors and electronic-mechanical dual-induction weighing systems, the machine eliminates human error in powder measurement. This ensures every melamine product receives identical material dosage, preventing defects such as short shots, flash formation, or density inconsistencies in final tableware products.
Significant Cost Reduction
  • Material Savings: Reduces melamine powder waste by 15-30% compared to manual weighing
  • Labor Optimization: Eliminates 1-2 operators per production line
  • Efficiency Gains: Increases overall production efficiency by 30%+ through continuous operation
Flexible Configuration Options
  • Adjustable Discharge Methods: Multiple blanking options available (39mm or 50mm interchangeable discharge openings)
  • Variable Lift Table: Height adjustment capability (±10cm) for ergonomic integration
  • Data Management: Electronic metering with counting, shortage alarm, cumulative recording, and data upload capabilities
Seamless Production Line Integration
Perfectly matches with automatic melamine molding machines, grinding/polishing equipment, and robotic handling systems to create fully automated manufacturing cells. Compatible with single-color and double-color melamine tableware production processes.
Industrial Melamine Tableware Auto Weighing Machine PLC Intelligent Control
Applications in Melamine Industry
Primary Applications
  • Melamine Dinnerware: Plates, bowls, cups, mugs, saucers
  • Serving Items: Trays, serving platters, compartment trays
  • Specialty Products: Custom-shaped tableware with decals and gold rim designs
  • Hotel & Restaurant Ware: Heavy-duty commercial-grade melamine crockery
Compatible Materials
  • A5 Melamine Molding Compound (Food grade, premium quality)
  • A1 Urea-Formaldehyde Powder (Electric jade powder)
  • LG Glazing Powder (Surface finishing compound)
  • Bakelite & Phenolic Resins (Thermosetting materials)
