Samsung 3.7 inch AMS369FG07-003 LCD Panel
Samsung 3.7 inch AMS369FG07-003 LCD Panel
Specifications
Place of Origin :
PHILIPPINE
Brand Name :
SAMSUNG
Certification :
Lead free / RoHS Compliant
Model Number :
AMS369FG07-003
MOQ :
1 PCS
Price :
Contact for Sample
Packaging Details :
MODULE
Delivery Time :
STOCK
Payment Terms :
T/T in advance, Paypal, Western Union
Supply Ability :
1000
Panel Model :
AMS369FG07-003
Panel Brand :
SAMSUNG
Descrition :
AM-OLED ,3.7 inch, 480×800
Panel Type :
AM-OLED
Description

Samsung 3.7 inch AMS369FG07-003 LCD Panel

Specification for AMS369FG07-003 :

Panel Model

AMS369FG07-003

Panel Brand

SAMSUNG SMD

Descrition

AM-OLED ,3.7 inch, 480×800

Panel Type

AM-OLED

Active Area

48.24×80.4 mm

Outline

53.94×90 mm

Surface

Hard coating (2H)

Contrast Ratio

1000 : 1 (Typ.)

Display Colors

262K (6-bit) , CIE1931 106%

Viewing Angle

80/80/80/80 (Typ.)(CR≥200) (L/R/U/D)

Frequency

60Hz

Driver IC

Built-in TL2796

Signal Interface

Parallel RGB (1 ch, 6-bit) + SPI , 39 pins

Input Voltage

2.8/2.8/4.6/-4.9V (Typ.)(IOVCC/VCI/ELVDD/ELVSS)
