LG Display 15.6inch LP156WH3-TLAC LCD Panel
LG Display 15.6inch LP156WH3-TLAC LCD Panel
Specifications
Place of Origin :
Japan
Brand Name :
LG Display
Certification :
RoHS Compliant
Model Number :
LP156WH3-TLAC
MOQ :
1 PCS
Price :
Pls Contact sales team
Packaging Details :
MODULE
Delivery Time :
stock
Payment Terms :
T/T , Paypal, Western Union Escrow etc.
Supply Ability :
1000
Panel Model :
LP156WH3-TLAC
Panel Brand :
LG Display
Descrition :
a-Si TFT-LCD ,15.6 inch, 1366×768
Panel Type :
a-Si TFT-LCD
Description

LG Display 15.6inch LP156WH3-TLAC LCD Panel

Specification for LP156WH3-TLAC:

LP156WH3-TLAC Basic Information

Panel Model

LP156WH3-TLAC

Panel Brand

LG Display

Descrition

a-Si TFT-LCD ,15.6 inch, 1366×768

Panel Type

a-Si TFT-LCD

Model Alias

LP156WH3 (TL)(AC)

Operating Temperature

0 ~ 50 °C

Storage Temperature

-20 ~ 60 °C

LP156WH3-TLAC Mechanical Features

Dot Resolution

1366(RGB)×768 (WXGA)

Pixel Configuration

RGB Vertical Stripe

Pixel Density

100 PPI

Aspect Ratio

16:9 (H:V)

Form Factor

Flat Rectangle Display

Dot Pitch

0.084×0.252 mm (H×V)

Pixel Pitch

0.252×0.252 mm (H×V)

Weight

420g (Max.)

Surface

Glare (Haze 0%), Hard coating (3H)

Active Area

344.232×193.536 mm (H×V)

Bezel Area

347.5×196.8 mm (H×V)

Outline Dimension

359.5×223.4 mm (H×V)

Outline Depth

3.8 (Max.) mm

Shape Style

Flat (PCBA Flat, Depth 3.4~4.0mm)

Holes & Brackets

Face mounting holes (8 pcs) on up, down slugs

Landscape or Portrait

Landscape type

Touch Panel

Without

LP156WH3-TLAC Optical Features

Display Mode

TN, Normally White, Transmissive

Brightness

200 cd/m² (Typ.)

Contrast Ratio

500 : 1 (Typ.) (Transmissive)

Display Color

262K (6-bit)

Color Gamut

45% NTSC (CIE1931)

Response Time

16 (Typ.)(Tr+Td)

Viewing Angle

40/40/10/30 (Min.)(CR≥10) (L/R/U/D)

Viewing Direction

6 o'clock

White color Chromaticity

Wx:0.313; Wy:0.329

White Variation

1.40/1.60 (Typ./Max.)(13 points)

Sunlight Readable

N

LP156WH3-TLAC Electronics Feature

Vertical Frequency

60Hz

Reverse Scan

No

Total Power Consumption

3.3W (Typ.)

LP156WH3-TLAC Backlight System

Lamp Position

Edge light type

Lamp Type

WLED

Lamp Amount

6 strings

Lamp Shape

6 strings

Lamp Life Time

12K(Min.) (Hours)

Interface Type

Included in panel signal interface

Lamp Driver Board

2.7/3.1W (Typ./Max.)

LP156WH3-TLAC Signal Interface

Signal Category

LVDS

Signal Class

LVDS (1 ch, 6-bit)

Input Voltage for Panel

3.3V (Typ.)

Input Current for Panel

190/240mA (Typ./Max.)

Panel Power Consumption

0.6/0.8W (Typ./Max.)

Interface Type

Connector

Interface Position

Signal Interface

UJU - IS050-L40B-C10, Pitch:0.5 mm, Pin:40 pins
