Toshiba 2.4inch LTM024DB40 LCD Panel
Toshiba 2.4inch LTM024DB40 LCD Panel
Specifications
Place of Origin :
Japan
Brand Name :
Toshiba
Certification :
RoHS Compliant
Model Number :
LTM024DB40
MOQ :
1 Pcs
Price :
Pls Contact sales team
Packaging Details :
MODULE
Delivery Time :
stock
Payment Terms :
T/T , Paypal, Western Union ,Escrow etc.
Supply Ability :
1000
Panel Model :
LTM024DB40
Panel Brand :
Toshiba
Descrition :
LTPS TFT-LCD ,2.4 inch, 240×320
Panel Type :
LTPS TFT-LCD
Description

Toshiba 2.4inch LTM024DB40 LCD Panel

Specification for LTM024DB40:

LTM024DB40 Basic Information

Panel Model

LTM024DB40

Panel Brand

Toshiba Matsushita

Descrition

LTPS TFT-LCD ,2.4 inch, 240×320

Panel Type

LTPS TFT-LCD

Operating Temperature

-20 ~ 70 °C

Storage Temperature

-30 ~ 80 °C

LTM024DB40 Mechanical Features

Dot Resolution

240(RGB)×320 (QVGA)

Pixel Configuration

RGB Vertical Stripe

Pixel Density

166 PPI

Aspect Ratio

3:4 (H:V)

Form Factor

Flat Rectangle Display

Dot Pitch

0.051×0.153 mm (H×V)

Pixel Pitch

0.153×0.153 mm (H×V)

Weight

6.9g (Typ.)

Active Area

36.72×48.96 mm (H×V)

Outline Dimension

42.22×59.06 mm (H×V)

Outline Depth

1.77 (Typ.) mm

Landscape or Portrait

Portrait type

Touch Panel

Without

LTM024DB40 Optical Features

Display Mode

VMW, Normally Black, Transflective

Brightness

260 cd/m² (Typ.)

Contrast Ratio

300 : 1 (Typ.) (Transmissive)

Display Color

262K (6-bit)

Color Gamut

60% NTSC (CIE1931)

Response Time

50/50 (Max.)(Tr/Td)

Viewing Direction

Symmetry

Reflectance Ratio

2.7% (Typ.)

Sunlight Readable

Y

LTM024DB40 Backlight System

Lamp Position

Edge light type

Lamp Type

WLED

Lamp Amount

1S4P

Lamp Shape

4 strings

Lamp Voltage

3.2/3.5V (Typ./Max.)

Lamp Current

20mA (Typ.)

Interface Type

Included in panel signal interface

Lamp Driver Board

No

LTM024DB40 Signal Interface

Signal Category

TTL

Signal Class

Parallel RGB (1 ch, 6-bit) + SPI

Input Voltage for Panel

2.8V (Typ.)

Input Current for Panel

4.6mA (Typ.)

Interface Type

FPC
