LG. LCD 17inch LM170E02-A5 LCD Panel
LG. LCD 17inch LM170E02-A5 LCD Panel
Specifications
Place of Origin :
Japan
Brand Name :
LG. LCD
Certification :
RoHS Compliant
Model Number :
LM170E02-A5
MOQ :
1 Pcs
Price :
Pls Contact sales team
Packaging Details :
MODULE
Delivery Time :
stock
Payment Terms :
T/T , Paypal, Western Union ,Escrow etc.
Supply Ability :
1000
Panel Model :
LM170E02-A5
Panel Brand :
LG. LCD
Descrition :
a-Si TFT-LCD ,17.0 inch, 1280×1024
Panel Type :
a-Si TFT-LCD
Description

LG. LCD 17inch LM170E02-A5 LCD Panel

Specification for LM170E02-A5:

LM170E02-A5 Basic Information

Panel Model

LM170E02-A5

Panel Brand

LG. LCD

Descrition

a-Si TFT-LCD ,17.0 inch, 1280×1024

Panel Type

a-Si TFT-LCD

Model Alias

LM170E02 (A5)

Operating Temperature

0 ~ 50 °C

Storage Temperature

-20 ~ 60 °C

Remarks

Super Narrow & Slim

LM170E02-A5 Mechanical Features

Dot Resolution

1280(RGB)×1024 (SXGA)

Pixel Configuration

RGB Vertical Stripe

Pixel Density

96 PPI

Aspect Ratio

5:4 (H:V)

Form Factor

Flat Rectangle Display

Dot Pitch

0.088×0.264 mm (H×V)

Pixel Pitch

0.264×0.264 mm (H×V)

Weight

1.89/1.94Kgs (Typ./Max.)

Surface

Antiglare, Hard coating (3H)

Active Area

337.92×270.336 mm (H×V)

Bezel Area

341.5×274.0 mm (H×V)

Outline Dimension

354.9×290.3 mm (H×V)

Outline Depth

12.8±0.5 mm

Holes & Brackets

Side mounting holes (4-M3) on left, right bezel

Landscape or Portrait

Landscape type

Touch Panel

Without

LM170E02-A5 Optical Features

Display Mode

TN, Normally White, Transmissive

Brightness

250 cd/m² (Typ.)

Contrast Ratio

500 : 1 (Typ.) (Transmissive)

Display Color

16.2M (6-bit + FRC)

Color Gamut

72% NTSC (CIE1931)

Response Time

3/9 (Typ.)(Tr/Td)

Viewing Angle

70/70/75/65 (Typ.)(CR≥10) (L/R/U/D)

White color Chromaticity

Wx:0.313; Wy:0.329

White Variation

1.30 (Max.)(5 points)

Sunlight Readable

N

LM170E02-A5 Electronics Feature

Vertical Frequency

60Hz

Reverse Scan

No

Total Power Consumption

19.2W (Typ.)

LM170E02-A5 Backlight System

Lamp Position

Edge light type (Top and Bottom)

Lamp Type

CCFL

Lamp Amount

4 pcs

Lamp Shape

Straight

Lamp Life Time

50K(Min.) (Hours)

Lamp Voltage

640/650/740V (Min./Typ./Max.)

Lamp Current

3.0/6.5/7.0mA (Min./Typ./Max.)

Lamp Operating Frequency

40/60/70KHz (Min./Typ./Max.)

Lamp Startup Voltage

1000/1250V (Max.)(Ta=+25/0℃)

Lamps Power Consumption

16.9/18.6W (Typ./Max.)

Interface Type

Connector

Lamp Driver Board

No

LM170E02-A5 Signal Interface

Signal Category

LVDS

Signal Class

LVDS (2 ch, 8-bit)

Input Voltage for Panel

5.0V (Typ.)

Input Current for Panel

460/530mA (Typ./Max.)

Panel Power Consumption

2.3/2.65W (Typ./Max.)

Interface Type

Connector

Signal Interface

HRS - MDF76LBRW-30S-1H, Pitch:1.0 mm, Pin:30 pins
