SAMSUNG 23inch LTA230AN03-W LCD Panel
SAMSUNG 23inch LTA230AN03-W LCD Panel
Specifications
Place of Origin :
Japan
Brand Name :
SAMSUNG
Certification :
RoHS Compliant
Model Number :
LTA230AN03-W
MOQ :
1 Pcs
Price :
Pls Contact sales team
Packaging Details :
MODULE
Delivery Time :
stock
Payment Terms :
T/T , Paypal, Western Union ,Escrow etc.
Supply Ability :
1000
Panel Model :
LTA230AN03-W
Panel Brand :
SAMSUNG
Descrition :
a-Si TFT-LCD ,23.0 inch, 1366×768
Panel Type :
a-Si TFT-LCD
Description

SAMSUNG 23inch LTA230AN03-W LCD Panel

Specification for LTA230AN03-W:

LTA230AN03-W Basic Information

Panel Model

LTA230AN03-W

Panel Brand

SAMSUNG

Descrition

a-Si TFT-LCD ,23.0 inch, 1366×768

Panel Type

a-Si TFT-LCD

Operating Temperature

0 ~ 50 °C

Storage Temperature

-20 ~ 60 °C

LTA230AN03-W Mechanical Features

Dot Resolution

1366×768(RGB) (WXGA)

Pixel Configuration

RGB Horizontal Stripe

Pixel Density

68 PPI

Aspect Ratio

16:9 (H:V)

Form Factor

Flat Rectangle Display

Dot Pitch

0.372×0.124 mm (H×V)

Pixel Pitch

0.372×0.372 mm (H×V)

Weight

1.70Kgs (Max.)

Surface

Antiglare (Haze 2.3%), Hard coating (2H)

Active Area

508.152×285.696 mm (H×V)

Bezel Area

513.8×290.8 mm (H×V)

Outline Dimension

534×311.8 mm (H×V)

Outline Depth

11±0.5 mm

Holes & Brackets

Side mounting holes (4-M3) on left, right bezel

Landscape or Portrait

Landscape type

Touch Panel

Without

LTA230AN03-W Optical Features

Display Mode

PVA, Normally Black, Transmissive

Brightness

250 cd/m² (Typ.)

Contrast Ratio

4000 : 1 (Typ.) (Transmissive)

Display Color

16.7M (8-bit)

Color Gamut

68% NTSC (CIE1931)

Response Time

8 (Typ.)(G to G)

Viewing Angle

89/89/89/89 (Typ.)(CR≥10) (L/R/U/D)

Viewing Direction

Symmetry

White color Chromaticity

Wx:0.285; Wy:0.311

White Variation

1.43 (Max.)(9 points)

Sunlight Readable

N

LTA230AN03-W Electronics Feature

Vertical Frequency

60Hz

Reverse Scan

No

LTA230AN03-W Backlight System

Lamp Position

Edge light type (Right side)

Lamp Type

WLED

Lamp Shape

1 string

Lamp Life Time

30K(Min.) (Hours)

Lamp Voltage

96.4/103.6/110.9V (Min./Typ./Max.)

Lamp Current

120/125mA (Typ./Max.)

Lamps Power Consumption

11.6/12.1/13.6W (Typ./Max.)

Interface Type

Connector

Interface Position

Lamp Driver Board

No

LTA230AN03-W Signal Interface

Signal Category

LVDS

Signal Class

LVDS (1 ch, 8-bit)

Input Voltage for Panel

12.0V (Typ.)

Input Current for Panel

216/316mA (Typ./Max.)

Interface Type

Connector

Interface Position
