Quick Detail:

PRECISION 2.5-VOLT REFERENCE

Description:

This monolithic integrated circuit is a fully self-contained precision voltage reference generator, internally trimmed for ±1% accuracy. Requiring less than 2mA in quiescent current, this device can deliver in excess of 10Ma with total load- and line-induced tolerances of less than 0.5%. In addition to voltage accuracy, internal trimming achieves a temperature coefficient of output voltage of typically 10 ppm/°C. As a result, these references are excellent choices for application to critical instrumentation and D-to-A converter systems.

The SG1503 is specified for operation over the full military ambient temperature range of -55°C to 125°C , while the SG2503 is designed for -25°C to 85°C and the SG3503 for commercial applications of 0°C to 70°C.

Applications:

•• Output voltage trimmed to ±1%

••• Input voltage range of 4.5 to 40V

••• Temperature coefficent of 10ppm/°C

••• Quiescent current typically 1.5mA

••• Output current in excess of 10mA

••• Interchangeable with MC1503 and AD580

Specifications:

Competitive Advantage:

Warranty :180 days !
Free shipping: Order over $1000 win a free shipment fee
(goods weight below 3Kg) ,during 20130901-20130930 .

Why buy from us >>> Fast / Safely / Conveniently

• Mega Source is a Stock keeper and trade company of Electronic components .Our branches office include China, Hong Kong, Sigapore , Canada . Offer business, service, resourcing and information for our global member.
• Goods are ensured the highest quality possible and are delivered to our customers all over the world with speed and precision.

How to buy >>>

• Contact us by email & sent your inquire with your Transport destination .
• Online chat, the commissioner would be responded ASAP.

Service >>>

• Forwarder Shipment to world-wide, DHL ,TNT ,UPS,FEDEX etc. buyer don`t need to worry about shipping problem
• We will try to respond as quickly as possible. But due to time zone difference, please allow up to 24 hours to get your mail replied. The products were tested by some devices or software, we ensure that there is no quality problems.
• We are committed to providing fast, convenient and safe transportation service to global buyer.
