AA057VF02 5.7inch Touch Screen Mitsubishi 640(RGB)×480 , VGA 400 cd/m² (Typ.)
AA057VF02 5.7inch Touch Screen Mitsubishi 640(RGB)×480 , VGA 400 cd/m² (Typ.)
AA057VF02 5.7inch Touch Screen Mitsubishi 640(RGB)×480 , VGA 400 cd/m² (Typ.)
AA057VF02 5.7inch Touch Screen Mitsubishi 640(RGB)×480 , VGA 400 cd/m² (Typ.)
AA057VF02 5.7inch Touch Screen Mitsubishi 640(RGB)×480 , VGA 400 cd/m² (Typ.)
AA057VF02 5.7inch Touch Screen Mitsubishi 640(RGB)×480 , VGA 400 cd/m² (Typ.)
Specifications
Place of Origin :
Japan
Brand Name :
Mitsubishi
Model Number :
AA057VF02
MOQ :
1 Pcs
Price :
Pls Contact sales team
Packaging Details :
Standard Packaging
Delivery Time :
1 day
Payment Terms :
T/T , Paypal, Western Union ,Escrow etc.
Supply Ability :
100
Panel Size :
5.7inch
Resolution :
640(RGB)×480 , VGA
Brightness :
400 cd/m² (Typ.)
Contrast Ratio :
600:1 (Typ.)
Display Colors :
262K (6-bit) , CIE1931 50%
Lamp Type :
WLED
Input Voltage :
3.3V (Typ.)(VCC)
Surface :
Clear, Hard coating (3H)
Description

AA057VF02 5.7inch Touch Screen Mitsubishi 640(RGB)×480 , VGA 400 cd/m² (Typ.)

Model Number:AA057VF02

1,Mitsubishi AA057VF02 Basic Information

Panel Brand : AA057VF02 5.7inch Touch Screen Mitsubishi 640(RGB)×480 , VGA 400 cd/m² (Typ.)
Panel Model : AA057VF02
Panel Type : a-Si TFT-LCD , Panel
Application :

AA057VF02 5.7inch Touch Screen Mitsubishi 640(RGB)×480 , VGA 400 cd/m² (Typ.)
Operating Temperature : -20 ~ 70 °C
Storage Temperature : -30 ~ 80 °C
RoHS : AA057VF02 5.7inch Touch Screen Mitsubishi 640(RGB)×480 , VGA 400 cd/m² (Typ.)

2,Mitsubishi AA057VF02 Mechanical Features

Panel Size : 5.7inch
Dot Resolution : 640(RGB)×480 (VGA)
Pixel Configuration : RGB Vertical Stripe
Pixel Density : 141 PPI
Aspect Ratio : 4:3 (H:V)
Form Factor : Flat Rectangle Display
Dot Pitch : 0.060×0.180 mm (H×V)
Pixel Pitch : 0.180×0.180 mm (H×V)
Weight : 165g (Typ.)
Surface : Clear, Hard coating (3H)
Active Area : 115.2×86.4 mm (H×V)
Bezel Area : 119.2×90.4 mm (H×V)
Outline Dimension : 135×104.6 mm (H×V)
Outline Depth : 8.85±0.5 mm
Holes & Brackets : Rear mounting holes (4-Ф2.6)
Landscape or Portrait : Landscape type
Touch Panel : Without

3,Mitsubishi AA057VF02 Optical Features

Display Mode : TN, Normally White, Transmissive
Brightness : 400 cd/m² (Typ.)
Contrast Ratio : 600 : 1 (Typ.) (Transmissive)
Display Color : 262K (6-bit)
Color Gamut : 50% NTSC (CIE1931)
Response Time : 5/20 (Typ.)(Tr/Td)
Viewing Angle : 80/80/80/60 (Typ.)(CR≥10) (L/R/U/D)
Viewing Direction : 6 o'clock
White color Chromaticity : Wx:0.313; Wy:0.329
White Variation : 1.30 (Max.)(5 points)

4,Mitsubishi AA057VF02 Electronics Feature

Vertical Frequency : 60Hz
Reverse Scan : Yes (U/D, L/R)
Total Power Consumption : 4.2W (Typ.)
Time Controller (T-CON) : Embedded T-CON

5,Mitsubishi AA057VF02 Backlight System

Lamp Position : Edge light type
Lamp Type : WLED
Lamp Life Time : 60K(Min.) (Hours)
Interface Type : Connector

6,Mitsubishi AA057VF02 Signal Interface

Signal Category : TTL
Signal Class : CMOS (1 ch, 6-bit)
Input Voltage for Panel : 3.3V (Typ.)(VCC)
Input Current for Panel : 300/400mA (Typ./Max.)(ICC)
Voltage for Display Signals : 0≤VIL≤0.8V; 2.0V≤VIH≤5.5V
Interface Type : Connector

Detail picture for AA057VF02 5.7inch Touch Screen Mitsubishi 640(RGB)×480 , VGA 400 cd/m² (Typ.)

AA057VF02 5.7inch Touch Screen Mitsubishi 640(RGB)×480 , VGA 400 cd/m² (Typ.)
