1/3 2.4-6.0mm 2Megapixel F1.6 M12x0.5 Mount Fixed IRIS Manual Zoom/Focus IR Vari-focal Lens
1/3 2.4-6.0mm 2Megapixel F1.6 M12x0.5 Mount Fixed IRIS Manual Zoom/Focus IR Vari-focal Lens
Specifications
Place of Origin :
China
Model Number :
1302406FM-M12-MP
Packaging Details :
Standard
Delivery Time :
2-7 work days
Supply Ability :
Samples available
Payment Terms :
T/T, Western Union, Moneygram, Paypal
Brand Name :
CCOM LENS
MOQ :
100pcs
Board Lens :
M12 Mount Varifocal Lens
Focal Length :
1/3" 2.4-6mm
Resolution :
2MP
Materials :
Metal + Glass
Description

Vari-Focal Lens

● Multi-mega pixels lens

● Compact design for Dome & Bullet cameras
● IR-collection for Day & Night surveillance

● IRIS option: Fixed, Auto (DC) drive

1/3" 2.4-6.0mm F1.6 1080P 2Megapixel M12x0.5 S-mount Fixed IRIS Manual Zoom/Foucs IR Vari-Focal Lens, 2.4-6mm fixed IRIS M12 lens

Model 1302406FM-M12-MP
IMAGE FORMAT 1/3"
FOCAL LENGTH 2.4~6mm
F.O.V (W~T) (D*H*V): D.FOV: 150.7°~59°, H.FOV: 112°~47°, V.FOV: 80°~35°
RESOLUTION MP
APERTURE F1.6~360
MOUNT M12*0.5
IRIS Fixed
ZOOM Manual
FOCUS Manual
M.O.D. 0.1m
B.F.L. 6.21~10.49mm
EFFECTIVE APERTURE Φ21.8mm (front), Φ5.9mm (rear)

IR COLLECTION YES
LENS CONSTRUCTION 9-7
DIMENSION Φ32×35.8mm

Tips:

- Fixed IRIS/DC Auto IRIS/P-IRIS option

- Manual/Motorized Zoom option

- M12/CS mount option

- IR/IR-CUT option

- IR-CUT: 650nm+AR IR-CUT filter switch; or IR-Cut filter if request.

- For more lenses, please feel free to contact us at sales01@megapixellenses.com; cctv.lens@ccom-tech.com
