GH-T6 4D Color Doppler Ultrasound System Machine OB GYN
GH-T6 4D Color Doppler Ultrasound System Machine OB GYN
GH-T6 4D Color Doppler Ultrasound System Machine OB GYN
GH-T6 4D Color Doppler Ultrasound System Machine OB GYN
GH-T6 4D Color Doppler Ultrasound System Machine OB GYN
GH-T6 4D Color Doppler Ultrasound System Machine OB GYN
GH-T6 4D Color Doppler Ultrasound System Machine OB GYN
GH-T6 4D Color Doppler Ultrasound System Machine OB GYN
GH-T6 4D Color Doppler Ultrasound System Machine OB GYN
GH-T6 4D Color Doppler Ultrasound System Machine OB GYN
Specifications
Brand Name :
GH
Model Number :
GHT6
Certification :
CE
Place of Origin :
CHN
MOQ :
2
Price :
1
Payment Terms :
L/C, D/A, D/P,T/T, Western Union, MoneyGram
Supply Ability :
50000
Delivery Time :
7
Packaging Details :
carton
Type :
Examination Therapy Equipments
Product name :
medical supplies and equipment
Instrument classification :
Class III
Warranty :
2 Years
Application :
GYN,Hospital,Veterinary,Clinic,Blood Vessel
Imaging mode :
B+B,B+M,M
Name :
Trolley Color Ultrasound Machine,Cardiac portable ultrasound machine price,Cardiac Portable Color Doppler Ultrasound,Cheap Ultrasound Machine,Wireless Color doppler Ultrasound Probe
Item :
Color Doppler System,ultrasound baby scan machine,Doppler portable ultrasound machine
Display mode :
B,B+B,M,B+M
Weight :
less than 7Kg
Usb ports :
support
Power supply :
AV220V±22V,50Hz/60Hz
Image/video forma :
DICOM,JPG,BMP,AVI,TIF
Description
GH-T6 High-end 4D Color Doppler Ultrasound System Machine OB/GYN Factory Price
Overview
Quick Details
Place of Origin:
Jiangsu, China
Brand Name:
GH
Model Number:
GH-T6
Power Source:
Electric
Warranty:
2 years, 2 years
After-sale Service:
Online technical support
Material:
Metal, Plastic, Steel
Shelf Life:
2 years
Quality Certification:
CE ISO
Instrument classification:
Class II
Safety standard:
GB
Type:
Doppler Ultrasound Equipment
Application:
GYN
Display mode:
2B, 4B, M, B/M, B/C, B/D, B/C/D, B/CFM/D, PDI
Display:
19 inch LED Monitor+10.4 inch touch screen
Operation system:
Windows 7 system
storage:
128G memory
Dynamic range:
20-280dB
Detecting depth:
320mm
probe interface:
4
Supply Ability
Supply Ability
500 Piece/Pieces per Month
Packaging & Delivery
Packaging Details
102*73*165cm, 119kg
Port
shenzhen/shanghai

Main Specification:

1 Main Specifications and System of Trolley 4D Color Doppler ultrasound
1.1 Trolley type all digital color Doppler ultrasonic mainframe
1.2 Windows 8 operating system
1.3 Spectrum pulse Doppler
1.4 Direction energy Doppler
1.5 Real time three synchronization
1.6 Space composite imaging: the requirement is 3 level, visual adjustable.
1.7 Organized harmonic imaging technology
1.8 4B imaging mode
1.9 One key intelligent optimization
1.10 Chinese and English interface, Chinese and English input, optional.
1.11 Monitor: 19 inches, high definition LED.
1.12 10.4 inches touch LED
1.13 Physical clipboard: save the image on the left side of the screen, which can be directly saved or deleted.
1.14 The system has the function of on-the-spot upgrade
1.15 Presupposition: for different inspection of the viscera, preset the inspection conditions for the best image, reduce the adjustment of the operation, and the commonly used external adjustment and combination regulation.
1.16 Support real-time 3D imaging function
1.17 The probe interface is 4
2 Probes
2.1 Convex array probe: 2.5MHz/3.0MHz/3.5MHz/4.0MHz/H4.0MHz/H5.0MHz,
2.2 Linear array probe: 6.0MHz/7.5MHz/8.5MHz/10.0MHz/H10.0MHz,
2.3 Trans-vaginal probe: 4.5MHz/6.0MHz/7.0MHz/9.0MHz/H8.0MHz,
2.4 Phased array probe: 2.5MHz/3.0MHz/3.5MHz/4.0MHz/H3.0MHz/H4.0MHz,
2.5 Micro convex probe: 4.5MHz/6.0MHz/7.0MHz/9.0MHz/H8.0MHz
2.6 4D Volume probe: 2.0MHz/3.0MHz/4.5MHz/6.0MHz/H5.0MHz,
2.7 The above probe has harmonic frequency
2.8 It can be selected according to customer needs: convex array probe, linear array probe, rectal probe, micro convex probe, phased array probe, volume probe.
2.9 Under each probe, there is a selection of specialist and viscera mode and rapid entry detection.
3 Two-dimensional imaging mode
3.1 Gain: 0-100, step 1 visible adjustable
3.2 TGC:8 segment adjustable
3.3 Image optimization: visible and adjustable over 7 levels
3.4 Dynamic range: 20-280dB 20 level visual adjustable
3.5 False color: 12, visible and adjustable
3.6 Smooth treatment: 8, visible and adjustable
3.7 Edge enhancement: 8, visible and adjustable
3.8 Sound power: 5% to 100%, step 5%, visible and adjustable
3.9 Display depth: greater than 317mm, less than 20mm, cardiac probe 371mm
3.10 Maximum focus number: 6 focal points, which can be moved throughout the whole process.
3.11 Scan line density more than 256 visible tunable
3.12 Gray scale: 0-7 level visible visible and adjustable
3.13 Filtering, 5 kinds
3.14 Scanning range, 50%-100%
3.15 Frame correlation, 0-4 level, visible and adjustable

GH-T6 4D Color Doppler Ultrasound System Machine OB GYNGH-T6 4D Color Doppler Ultrasound System Machine OB GYNGH-T6 4D Color Doppler Ultrasound System Machine OB GYNGH-T6 4D Color Doppler Ultrasound System Machine OB GYNGH-T6 4D Color Doppler Ultrasound System Machine OB GYN
