Sandblasting Scale 304 Stainless Steel Inclined Puncture Needle
Sandblasting Scale 304 Stainless Steel Inclined Puncture Needle
Sandblasting Scale 304 Stainless Steel Inclined Puncture Needle
Sandblasting Scale 304 Stainless Steel Inclined Puncture Needle
Sandblasting Scale 304 Stainless Steel Inclined Puncture Needle
Sandblasting Scale 304 Stainless Steel Inclined Puncture Needle
Sandblasting Scale 304 Stainless Steel Inclined Puncture Needle
Sandblasting Scale 304 Stainless Steel Inclined Puncture Needle
Sandblasting Scale 304 Stainless Steel Inclined Puncture Needle
Sandblasting Scale 304 Stainless Steel Inclined Puncture Needle
Sandblasting Scale 304 Stainless Steel Inclined Puncture Needle
Sandblasting Scale 304 Stainless Steel Inclined Puncture Needle
Sandblasting Scale 304 Stainless Steel Inclined Puncture Needle
Sandblasting Scale 304 Stainless Steel Inclined Puncture Needle
Sandblasting Scale 304 Stainless Steel Inclined Puncture Needle
Sandblasting Scale 304 Stainless Steel Inclined Puncture Needle
Sandblasting Scale 304 Stainless Steel Inclined Puncture Needle
Sandblasting Scale 304 Stainless Steel Inclined Puncture Needle
Sandblasting Scale 304 Stainless Steel Inclined Puncture Needle
Sandblasting Scale 304 Stainless Steel Inclined Puncture Needle
Specifications
Brand Name :
yue lin sen
Model Number :
Y2259
Certification :
ISO9001 ISO13485
Place of Origin :
Dongguan, Guangdong
MOQ :
100 pcs
Price :
0.5-20
Payment Terms :
T/T
Supply Ability :
5000000pcs
Delivery Time :
5-8 working days
Packaging Details :
Vacuum packaging carton
Transport Package :
Paper Box or Wooden Box
Strength :
High tensile strength
Finish :
Polished or Matte
Corrosionresistance :
High
Feature :
Stainless Steel Capillary Tube
Model No :
18G
Reusability :
Single-use or Reusable depending on type
Technique :
Cold Drawn
Specification :
0.8*0.15*210
Usage :
Medical, Sewing, Industrial
Application :
medical experimental needles
Trademark :
yue lin sen
Special Use :
Wear Resistant Steel
Tiptype :
Sharp or Blunt
Origin :
Dongguan, China
Description

Sandblasting Scale 304 Stainless Steel Inclined Puncture Needle

Sandblasting Scale 304 Stainless Steel Inclined Puncture Needle

Product Application:

This is a specialized medical/surgical puncture needle designed for procedures requiring precise depth control and secure handling, often in contexts where a standard hypodermic needle is insufficient.

  • Orthopedic Procedures: Bone marrow aspiration/biopsy, joint aspiration (arthrocentesis), or injections into bony or dense tissue sites.

  • Interventional Radiology: Guiding needle for drain placements or as an initial access needle for Seldinger technique in vascular or fluid collection procedures.

  • Veterinary Medicine: Large animal joint taps or fluid sampling where a robust, clearly marked needle is required.

  • Specialized Laboratory Sampling: Percutaneous fluid collection from research animals or for sampling from sealed containers where depth penetration is critical.

Product Description:

This product is a sterile, single-use puncture needle crafted from 304 stainless steel, featuring several key user-focused enhancements. It has a standard beveled point (common angles: 12°, 15°, or 20°) for efficient tissue penetration. The needle shaft undergoes uniform sandblasting, which provides a matte, non-reflective finish. This improves grip for the clinician and reduces glare under procedure lights. Most distinctively, the needle features permanent, laser-engraved depth graduations (刻度) along its length, typically at 1cm or 5mm intervals. These high-contrast markings allow for real-time visual confirmation of insertion depth, enhancing procedural accuracy and safety. It is a fundamental, reliable tool optimized for controlled percutaneous access.

Product Technical Parameters:

Category Parameter Details / Specification
Base Material Material 304 Stainless Steel (AISI 304, UNS S30400)
Properties Good corrosion resistance, high strength, suitable for medical use.
Needle Design Tip Geometry Standard Bevel (Hypodermic point). Common bevel angles: 12°, 15°, 20°.
Cannula Straight, rigid cannula. Can be styletted (solid) or hollow for aspiration/injection.
Dimensions Gauge (Outer Diameter) Common range: 14G (2.1mm) to 22G (0.7mm). Fully customizable.
Length Standard lengths: 1.5" (38mm), 2.5" (64mm), 3.5" (89mm), 5" (127mm). Custom lengths available.
Surface & Markings Surface Finish Uniform Sandblasted (Matte) Finish across the shaft. Enhances grip and reduces light reflection.
Depth Graduations Laser-Engraved Markings. Typical increments: 1 cm or 5 mm. Clear, permanent, and biocompatible.
Graduation Accuracy Marking position tolerance: ± 0.5 mm.
Hub & Connection Hub (if attached) Standard Luer-Lock hub (polypropylene or polycarbonate) in a neutral color (e.g., clear, white). Hubless (plain shaft) designs also possible.
Performance Sharpness Meets relevant sharpness standards for penetration force.
Rigidity Designed to resist bending during insertion into dense tissue.
Sterility & Compliance Sterilization Provided STERILE (Ethylene Oxide or Gamma Irradiation). SAL 10⁻⁶.
Single-Use Intended for single patient use only.
Packaging Individually packed in a peel-open blister pack or Tyvek® pouch.
Standards Manufactured per ISO 13485 quality standards. Needle design conforms to general principles of ISO 7864.
