10/100/1000 Base-TX To 1000 Base-FX 1*9 Fiber Managed Media Converter Remote Standalone
10/100/1000 Base-TX To 1000 Base-FX 1*9 Fiber Managed Media Converter Remote Standalone
10/100/1000 Base-TX To 1000 Base-FX 1*9 Fiber Managed Media Converter Remote Standalone
10/100/1000 Base-TX To 1000 Base-FX 1*9 Fiber Managed Media Converter Remote Standalone
10/100/1000 Base-TX To 1000 Base-FX 1*9 Fiber Managed Media Converter Remote Standalone
10/100/1000 Base-TX To 1000 Base-FX 1*9 Fiber Managed Media Converter Remote Standalone
Specifications
Brand Name :
Fiberroad
Certification :
CE ISO9000 SGS FCC
Place of Origin :
China
MOQ :
1pair
Price :
Pls send request details
Model Number :
FR-6103R-XXXX
Payment Terms :
T/T, Western Union
Supply Ability :
5000pcs/Month
Delivery Time :
2-3 workdays
Packaging Details :
Standard neutral or brand packing
Standard :
IEEE802.3 ,IEEE802.3u,IEEE802.3Z,IEEE802.3x
Wavelength :
850nm/1310nm/1550nm
Connector :
SC,FC,ST,LC
Power Dissipation :
<3W
Temperature :
0 ~ 50 ℃
Humidity :
5%~90%
Description

10/100/1000Base-TX to 1000Base-FX 1*9 Fiber Managed Media Converter

10/100/1000Base-TX to 1000Base-FX 1*9 Fiber Managed Media Converter can be used in 16-slot multifunctional management system, which is a Ethernet and SDH transmission equipment, support mutiple services including managed media converter card, OEO Converter card, 1+1 protection switching card, CWDM/DWDM MUX/DEMUX Card, etc. supports protocols like SNMP, WEB, CONSOLE and TELNET ,with a strong management function , and operate easily to meet different customer's requirement.

Fiber Managed Media Converter Key Features

  • Supporting 10/100/1000M, full/half duplex autosensing
  • Supporting auto-MDI/MDIX
  • Supporting 1*9 transceiver, SFP transceiver optional
  • Support SFP DMI(Diagnostic Monitoring Interface) function
  • Supporting 850nm, 1310nm, 1550nm and DWDM/CWDM wavelength ruled by ITUT
  • Max. 2046 bytes packet at store-and-forward mode; Max. 9K bytes packet at cut-through
  • Rate Limit function, 32Kbps
  • Supporting Loopback, precisely locating the failure, convenient for link test
  • Supporting LFP, quickly locates the failure
  • Supporting remote power off alarming
  • Economical management function within bandwidth, supporting 802.3ah and TS 1000
  • With powerful network management function, supporting WEB and SNMP
  • Supporting hot plug
  • Supporting Remote management
  • Easy installation with complete LED indicators for working situation
  • Supporting 2U chassis (16 slots) and standalone use

Fiber Managed Media Converter Specification

Technical Parameter

Access Method

1X10/100/1000M RJ45

1X1000Base-FX (1*9 module)

Standard

IEEE802.3 ,IEEE802.3u,IEEE802.3Z,IEEE802.3x

Wavelength

850nm/1310nm/1550nm

Connector

SC,FC, ST, LC

Power Dissipation

<3W

Operating Temperature

0 ~ 50 ℃

Humidity

5%~90%

Storage Temperature

-40~ 70 ℃

Dimension:

156mm (W)×128mm(D)×32 mm(H) (standalone)

112.8mm (W)×77.2mm(D)×23 mm(H) (Card)

Ordering Information

P/N

Description

X

X

X

X

FR-6103R-XXXX

10/100/1000Base-TX to 1000Base-FX

Media Converter (Remote Standalone)

S: Duplex Single-mode

M: Duplex Multi-mode

B: Simplex Single-mode

SFP: SFP Slot

3: TX 1310nm

4: TX 1490nm

5: TX 1550nm

8: TX 850nm

S: SC

F: FC

T: ST

L: LC

05: 550M

2: 2KM

20: 20KM

40: 40KM

FR-6103-XXXX

10/100/1000Base-TX to 1000Base-FX

Media Converter Card

10/100/1000 Base-TX To 1000 Base-FX 1*9 Fiber Managed Media Converter Remote Standalone 10/100/1000 Base-TX To 1000 Base-FX 1*9 Fiber Managed Media Converter Remote Standalone10/100/1000 Base-TX To 1000 Base-FX 1*9 Fiber Managed Media Converter Remote Standalone 10/100/1000 Base-TX To 1000 Base-FX 1*9 Fiber Managed Media Converter Remote Standalone
