SFP+ 10G Ethernet Converter 10G LAN / RJ45 With Jumbo Frame
SFP+ 10G Ethernet Converter 10G LAN / RJ45 With Jumbo Frame
SFP+ 10G Ethernet Converter 10G LAN / RJ45 With Jumbo Frame
SFP+ 10G Ethernet Converter 10G LAN / RJ45 With Jumbo Frame
SFP+ 10G Ethernet Converter 10G LAN / RJ45 With Jumbo Frame
SFP+ 10G Ethernet Converter 10G LAN / RJ45 With Jumbo Frame
Specifications
Brand Name :
Fiberroad
Model Number :
FR-6601R-XXX
Certification :
ISO9000, CE, FCC, RoHS
Place of Origin :
China
MOQ :
1pc
Price :
Pls send request details
Payment Terms :
T/T, Western Union, L/C
Supply Ability :
5000pcs/Month
Packaging Details :
Standard neutral or brand packing
Delivery Time :
2-3 workdays
Transmission Speed :
10Gb/s
Protocols :
IEEE802.3an,IEEE802.3ae
Access Type :
10Gb LAN
Interface Type :
RJ45 to/from SFP+/XFP
Transmission Distance :
80KM
Dimensions :
156mm * 128mm * 32mm
Description

SFP+ 10G Ethernet Converter 10G LAN / RJ45 With Jumbo Frame

This product is high-performance 10G optical media converter , Using Optical - Electrical - Electrical wavelength conversion, realize the optical signal equilibrium amplification, clock extraction and optical regeneration, and with WDM (DWDM/CWDM) technology, can achieve optical signals transmit in a single fiber by single or multiple way over a long distance. On the existing network infrastructure, it can quickly improve the communication capacity, expand the bandwidth, while using low cost and high cost-effective solutions to manage and operate the system, easy operation and maintenance.

Key Features

  • Support Jumbo Frame
  • Transparent Transport and very low delay
  • Support ITUT prescribed DWDM/CWDM wavelength
  • Support Loopback test function
  • Support hot plugging
  • Full State Led display
  • Easy installation

Specifications

Transmission mode

Technical Indexes

Transmission Speed

10Gb/s

Protocols

IEEE802.3an(10Gbase-T)

IEEE802.3ae(10Gbase-SR/LR/ER/ZR)

Access Type

10G LAN

Interface Type

RJ45 To/From SFP+

RJ45 To/From XFP

Transmission Distance

SFP+ module: Up to 80Km

XFP module:Up to 80Km

10Gbase-T: 100meters Cat .6a cable

Maximum Packet

Forwarding Rate

14,880,950/S

Power supply specifications and dimensions

AC:100V~240V 50~60HZ

DC:40V~50V 50~60HZ

power consumption≤6W(without module)

External AC-DC 20W

communication module power

156mm * 128mm * 32mm

PS.: *Specifications subject to change without notice.

SFP+ 10G Ethernet Converter 10G LAN / RJ45 With Jumbo Frame

Ordering Informations

P/N

Description

Remark

FR-6601R-SFP+

10G Media Converter

SFP+ to RJ45

FR-6601R-XFP

10G Media Converter

XFP to RJ45
