Product Overview

Technical Specifications

• Material Number: R165142320
• Size: 45 mm
• Design: FNS (flangeless, normal length, standard height)
• Material: Carbon steel (CS)
• Preload Class: C2 (average preload)
• Accuracy Class: H (high)
• Ball Chain: Without ball chain
• Dimensions:
  • Width (A): 120 mm
  • Height with Rail (H): 137.6 mm
  • Length (B): 137.6 mm
• Load Capacity:
  • Dynamic Load Capacity (C): 84000 N
  • Static Load Capacity (C0): 130000 N
• Temperature Range: -10°C to +80°C
• Friction Coefficient (μ): 0.002 to 0.003
• Sealing: Standard seal
• Lubrication: Pre-lubricated with Dynalub 510 grease

Features

• High Rigidity: Ensures stability and precision in demanding applications.
• Average Preload: Reduces friction and improves efficiency.
• High Accuracy: Suitable for applications requiring high precision.
• Robust Design: Made from carbon steel for durability.
• Long-Term Lubrication: Pre-lubricated at the factory, allowing for long-term use without frequent maintenance.
• Versatile Compatibility: Can be used on all SNS/SNO ball guide rails.

Applications

• CNC Machines: Ensures precise tool positioning and movement.
• Automation Systems: Provides smooth and accurate linear motion for automated processes.
• Robotics: Facilitates precise movements in robotic arms and platforms.
• Material Handling Equipment: Enhances the efficiency of systems requiring precise linear motion for transporting goods.

Supplier Information

• BuyRexroth: Provides detailed product information and support.
• SP-SpareParts: Ships within 1 to 3 days to the United States.
• Simply Bearings: Offers the product with detailed specifications.
