Product Description:

Advantages and features of Rexroth printed circuit boards

‌High integration and structural stability‌

The use of substrates such as epoxy resin glass fiber cloth (FR-4) combined with precision lamination technology provides excellent mechanical strength and electrical performance, supporting complex circuit layouts while ensuring long-term stability.

The multi-layer composite design supports high-density wiring and reduces signal transmission loss, which is suitable for scenarios such as servo systems and CNC machine tools that have strict requirements on space and precision.

‌Electrical performance optimization‌

The copper foil conductive path achieves low-impedance connection through etching process, and high-purity materials are used to reduce high-frequency signal interference and improve overall circuit efficiency.

Supports multiple signal transmission types (such as digital, analog, and radio frequency microwaves), and integrates anti-interference design to ensure signal integrity.

‌Manufacturing process and durability‌

The automated production process combined with computer control technology achieves high-precision, high-efficiency large-scale manufacturing and reduces production costs.

Discrete components (such as capacitors and resistors) use high-temperature resistant and anti-aging materials to reduce the risk of failure caused by overheating or voltage fluctuations.

‌Compatibility and expansion capability‌

The standardized design is compatible with other Rexroth control systems (such as servo drives) and supports communication interfaces such as Profibus and Profinet, which facilitates industrial system integration.

Precautions for use

‌Installation and environmental requirements‌

Avoid using in high temperature, dusty or humid environments to prevent deformation of the substrate or oxidation of the copper foil, which may lead to performance degradation.

During installation, ensure that the circuit board and the device interface are accurately aligned to avoid mechanical stress causing cracking of the solder joints or separation of the laminate.

‌Operation specification‌

Before powering on, check whether the power supply voltage meets the rated value to prevent overvoltage or undervoltage from burning the components.

It is prohibited to frequently switch the power supply on and off or force overload operation to avoid overheating or instantaneous current shock.

‌Maintenance and troubleshooting‌

Regularly clean the oil and dust on the surface of the circuit board, use a soft brush with a special cleaner to avoid corrosive solvents from damaging the insulation layer.

Check whether the electrolytic capacitor is bulging and the resistor is burnt, and replace the aging parts in time; if the copper foil is broken or the solder joint is detached, professional repair is required.

‌Special scenario protection‌

When used in areas with lightning risk or strong electromagnetic interference, it is recommended to add a shielding cover or surge protection device.

Bending the circuit board is prohibited during physical transportation. It must be packaged in an anti-static package and fixed in a special bracket.

‌Note‌: In actual application, it is necessary to combine the specific model parameter manual and give priority to the original factory recommended accessories.
