8 Channel 1080P AHD HD Hard Disk Storage Vehicle 3G Special Function Mobile DVR Camera
8 Channel 1080P AHD HD Hard Disk Storage Vehicle 3G Special Function Mobile DVR Camera
8 Channel 1080P AHD HD Hard Disk Storage Vehicle 3G Special Function Mobile DVR Camera
8 Channel 1080P AHD HD Hard Disk Storage Vehicle 3G Special Function Mobile DVR Camera
8 Channel 1080P AHD HD Hard Disk Storage Vehicle 3G Special Function Mobile DVR Camera
8 Channel 1080P AHD HD Hard Disk Storage Vehicle 3G Special Function Mobile DVR Camera
8 Channel 1080P AHD HD Hard Disk Storage Vehicle 3G Special Function Mobile DVR Camera
8 Channel 1080P AHD HD Hard Disk Storage Vehicle 3G Special Function Mobile DVR Camera
8 Channel 1080P AHD HD Hard Disk Storage Vehicle 3G Special Function Mobile DVR Camera
8 Channel 1080P AHD HD Hard Disk Storage Vehicle 3G Special Function Mobile DVR Camera
8 Channel 1080P AHD HD Hard Disk Storage Vehicle 3G Special Function Mobile DVR Camera
8 Channel 1080P AHD HD Hard Disk Storage Vehicle 3G Special Function Mobile DVR Camera
Specifications
Place of Origin :
Guangdong, China
Brand Name :
Richmor
Model Number :
RCM-MDR7208-008
MOQ :
2 pieces
Price :
$186.00/pieces 2-49 pieces
Product name :
RCM-MDR7208
Storage :
1*2TB HDD + 1*128GB SD Card
Special Function :
3G, 4G,GPS,Wifi(Optional)
Video/Audio Input :
8 Channels
Resolution :
1080P/720P/CIF/HD1/D1
Video Compression :
H.264
Alarm Input :
8 Channels
Alarm Output :
2 Channels
Voltage :
8-36V
Video Compression Format :
H.265
Description

8 Channel 1080P AHD HD Hard Disk Storage Vehicle 3G Special Function Mobile DVR Camera

Richmor Factory Direct Sell 8 Channel 1080P AHD HD Hard Disk Storage Vehicle Mobile DVR 3G 4G GPS Wifi optional

PRODUCT DESCRIPTION
Resolution 8X 1080P AHD Full real-time recording
Moduel G-Sensor built in, GPS /3G/4G /WIFI Optional
Storage Support 1X2TB Hard disk+ 1X128 GB SD card
Alarm I/O 8CH Alarm input, 2CH Alram output
ACC Delay 10 seconds delay pow-off for data protection
Voltage 6V-36V Wide range voltage power supply

8 Channel 1080P AHD HD Hard Disk Storage Vehicle 3G Special Function Mobile DVR Camera

8 Channel 1080P AHD HD Hard Disk Storage Vehicle 3G Special Function Mobile DVR Camera

Detailed specification was listed as follows for checking, please contact us we'll do our best to cooperate.

Item

Parameter

OS

Linux

Language

Chinese/English/Others(can be customized)

Video Compression

H.264

OSD

Overlays information such as date time and vehicle ID

Video

Record

System

Video Input

Support 8 CH Full real-time AHD 1080P

Video Output

2CH CVBS+ VGA output for optional, 1.0Vp-p, 75Ω

Preview

Support 1 channel and 4 channels preview.,Support Manual/Alarm Trigger full screen preview

Video Quality

0-7 levels, 0 is the highest level, 7 is the lowest level.

Resolution

Support 4CH Full real-time AHD 1080P

Record Mode

The default setting is auto recording after power on. Timed recording, alarm trigger recording and manual recording are supported.

Audio

Audio Input

4CH

Audio Output

2CH

Compression

G.726

Alarm

Input

8CH

Output

2CH

Storage

Up to 2TB HDD & 128GB SD Card

Communication Port

3CH RS232 / 2CH RS485

G-sensor

Built in, support 3 Axis Motion Detection with user set ranges , for X,Y and Z coordinates

Wireless communications

GPS /3G /4G /WIFI optional

GPS

Support Built GPS/BD Module,can support the ministry of communications

Video Playback

Video Search

Search video by Record Time/Type etc

Playback

Max support 8CH Replay /Stop/Fast Forward/Fast Reverse at same time

CMS

Wireless(require Wi-Fi or cellular), real-time monitoring .GPS and alarm etc

Operating Voltage

Voltage Input

8V ~ 36V DC

Voltage Output

12V 2.5A

5V 2.5A

Power -off Protection

All video information can be saved automatically when the power cut off, and make sure that all the files can not be damaged

Power Consumption

Normal Working <10W

Other

Operation Temperature

-20℃ ~ + 70℃

Humidity

20% ~ 80%

Dimension

200*187*62mm

Weight

1.9KG

8 Channel 1080P AHD HD Hard Disk Storage Vehicle 3G Special Function Mobile DVR Camera

8 Channel 1080P AHD HD Hard Disk Storage Vehicle 3G Special Function Mobile DVR Camera

RCM-MDR7104
a. Remote controller*1 b. 6PIN power cable*1 c. 16PIN output*1
d. 24PIN alarm cable*1 e. VGA switching cable(6 pin)*1 f. USB cable*1
g. 4G antenna

h. GPS antenna

 i. WIFI antenna

8 Channel 1080P AHD HD Hard Disk Storage Vehicle 3G Special Function Mobile DVR Camera8 Channel 1080P AHD HD Hard Disk Storage Vehicle 3G Special Function Mobile DVR Camera8 Channel 1080P AHD HD Hard Disk Storage Vehicle 3G Special Function Mobile DVR Camera8 Channel 1080P AHD HD Hard Disk Storage Vehicle 3G Special Function Mobile DVR Camera8 Channel 1080P AHD HD Hard Disk Storage Vehicle 3G Special Function Mobile DVR Camera8 Channel 1080P AHD HD Hard Disk Storage Vehicle 3G Special Function Mobile DVR Camera

8 Channel 1080P AHD HD Hard Disk Storage Vehicle 3G Special Function Mobile DVR Camera8 Channel 1080P AHD HD Hard Disk Storage Vehicle 3G Special Function Mobile DVR Camera

Shenzhen Richmor Technology Development CO.,LTD

[ 100% OEM Manufacturer, Quality Assured, Price Competitive]

Contact: Ada Lin

Mob: + 86 18938073583

Skype: + 86 18938073583

Website: http://www.mdvrchina.com

Company Add: 5th Floor, D Building, Bantian International Center, Bantian, Longgang District, Shenzhen, China.
