100V BUK7240-100A,118 MOSFET Chips Low On Resistance For Power Electronics
100V BUK7240-100A,118 MOSFET Chips Low On Resistance For Power Electronics
Specifications
Description :
The BUK7240-100A,118 belongs to the category of MOSFET (Metal-Oxide-Semiconductor Field-Effect Transistor) chips
Stock :
5200-20000
MOQ :
1000pcs
Price :
Negotiated
Payment Terms :
T/T
Shipping Method :
LCL, AIR, FCL, Express
Drain-Source Voltage (Vdss) :
100V
Continuous Drain Current (Id) :
Up to 34A (Tc) at 25°C
Gate-Source Threshold Voltage :
4V @ 1mA
Description

The BUK7240-100A,118 belongs to the category of MOSFET (Metal-Oxide-Semiconductor Field-Effect Transistor) chips, specifically an N-channel MOSFET. This chip is manufactured by Nexperia and features a set of specific electrical characteristics and packaging specifications.

Here are some key parameters and characteristics of the BUK7240-100A,118 chip in English:

  1. Electrical Characteristics:
    • Drain-Source Voltage (Vdss): 100V
    • Continuous Drain Current (Id): Up to 34A (Tc) at 25°C
    • Gate-Source Threshold Voltage (Vgs th): 4V @ 1mA
    • Drain-Source On-Resistance (Rds On): 40mΩ @ 25A, 10V
    • Maximum Power Dissipation (Pd): Up to 114W (Tc) at Ta=25°C
  2. Packaging Specifications:
    • The package format may include SOT428, DPAK, SOT-252, etc., depending on different suppliers or batches.
    • The package body material is typically PLASTIC/EPOXY, providing good insulation and heat dissipation properties.
  3. Operating Temperature Range:
    • Minimum Operating Temperature: -55°C
    • Maximum Operating Temperature: +175°C
  4. Other Features:
    • Channel Mode: Enhancement Mode
    • Transistor Polarity: N-Channel
    • RoHS: Yes (indicating compliance with the European Union's RoHS directive, which restricts the use of certain hazardous substances)

The BUK7240-100A,118 chip, with its high current-handling capability, low on-resistance, and wide operating temperature range, finds widespread applications in power electronics, motor drives, power management, and other fields. It can be used as a switching element to control the ON/OFF state of a circuit, enabling precise control and regulation of current flow.100V BUK7240-100A,118 MOSFET Chips Low On Resistance For Power Electronics
