Fine Grain EDM Graphite Blocks High Accuracy Electrical Discharge Machining
Fine Grain EDM Graphite Blocks High Accuracy Electrical Discharge Machining
Specifications
color :
black
Place of Origin :
China
Brand Name :
Fangda
Certification :
Iso9001
MOQ :
1 piece
Packaging Details :
Plywood case
Shape :
solid block
Material :
isostatic graphite
Description

High Accuracy Fine Grain EDM Graphite Blocks – Industrial-Grade Description

High Accuracy Fine Grain EDM Graphite Blocks with High Density for Precision Machining

High accuracy fine grain EDM graphite blocks are engineered for precision machining applications requiring tight tolerances and superior surface integrity. Manufactured from high-density, ultra-fine grain graphite, these blocks deliver excellent isotropy, low porosity, and consistent electrical conductivity, ensuring stable and efficient EDM performance. Their optimized microstructure minimizes electrode wear and enables fine detail reproduction with high dimensional accuracy. With low thermal expansion and strong resistance to thermal shock, they maintain structural stability during high-speed discharge cycles. Widely used in mold making, aerospace components, and precision tooling, these graphite blocks ensure reliability, repeatability, and extended service life.

Grade Bulk Density (g/cm³) Electric Resistivity (μΩ·m) Compressive Strength (MPa) Flexural Strength (MPa) Shore Hardness Ash Content (ppm) Coefficient of Thermal Expansion (×10⁻⁶/℃) Thermal Conductivity (W/m·K) Particle Size (μm) Applications
EDM-10 1.86 12 110 52 66 200 6 100 10 EDM Precise Machining Molds
EDM-60 1.88 11 140 70 66 200 5.7 100 6 EDM Precise Machining Molds
EDM-T8 1.75 13 90 50 60 200 6 100 8 High-precision electrode, 3D curved glass molds of mobile phone
EDM-T5 1.77 14 100 55 65 200 5.8 100 5 High-precision electrode, 3D curved glass molds of mobile phone
EDM-T3 1.75 16 120 65 68 200 5.8 85 3 High-precision electrode, 3D curved glass molds of mobile phone
