PVC Plastic Drainage Board Fast Installation Vertical Drain System
PVC Plastic Drainage Board Fast Installation Vertical Drain System
PVC Plastic Drainage Board Fast Installation Vertical Drain System
PVC Plastic Drainage Board Fast Installation Vertical Drain System
PVC Plastic Drainage Board Fast Installation Vertical Drain System
PVC Plastic Drainage Board Fast Installation Vertical Drain System
Specifications
Material :
PVC HDPE
MOQ :
1000pcs
Payment Terms :
T/T
Roll Length :
5–15m
Temperature Range :
-10℃ to 80℃
Place of Origin :
China
Packaging Details :
Woven fabric packaging
Delivery Time :
5 days
Width :
1–3m
Supply Ability :
9999999㎡/MONTH
Brand Name :
YPEP
Height :
20mm–30mm
Drainage Capacity :
≥10 cm³/s
Tensile Force :
≥350N
Compression Resistance :
≥300KPa
Description
Product Description

PVC Plastic Drainage Board is designed for rapid soil consolidation and efficient subsurface water removal. Its structured core design creates continuous vertical drainage channels, accelerating pore water dissipation and improving soil bearing capacity.

This product is especially effective in projects involving deep soft clay layers where traditional drainage systems are inefficient. Its excellent ductility ensures adaptability to soil deformation without compromising drainage performance.

The board structure minimizes clogging risks and maintains consistent permeability over time. It is widely applied in infrastructure projects where durability and efficiency are critical.

Technical Specification Table
Item Unit Value
Material — PVC HDPE
Height mm 20 / 25 / 30
Width m 1–3
Length m 5–15
Tensile Strength N/100mm ≥350
Max Tensile Force N/100mm ≥600
Elongation % ≥25
Compression Strength KPa ≥300
Flow Rate cm³/s ≥10
Tear Strength N ≥100
Low Temp Flexibility ℃ No crack
Heat Aging % ≥80

PVC Plastic Drainage Board Fast Installation Vertical Drain SystemPVC Plastic Drainage Board Fast Installation Vertical Drain System

Why Choose Us

We focus on providing cost-effective drainage solutions with consistent quality.

Our materials are optimized for long-term durability, ensuring stable performance in both hot and cold environments. We offer flexible customization for roll size and thickness, allowing buyers to match project-specific requirements.

With strong production capacity, we ensure fast delivery even for large infrastructure projects.

FAQ

Q1 Is installation complicated
A No it uses standard insertion machines and is very efficient

Q2 Can it handle heavy loads
A Yes it maintains drainage under high compression

Q3 Does it clog easily
A No the structure minimizes blockage risk
