Specifications
Delivery Time :
5 days
Place of Origin :
China
Certification :
ISO9001
Payment Terms :
T/T
Packaging Details :
Woven fabric packaging
Supply Ability :
9999999㎡/MONTH
Brand Name :
YPEP
MOQ :
1000pcs
Description
Plastic HDPE Reinforcement Geocell for Breakwater/Slope Protection
Product Description

The geocell is a three-dimensional grid cell structure formed by reinforced HDPE material with ultrasonic welding. And it is a three-dimensional network after being ex- panded. Due to engineering needs, some holes are punched in the diaphragm. It is mainly divided into geocell, high-strength geocell, and honeycomb restraint sys- tem (Honeycomb restraint system: it is a three-dimensional network made of polymer broadband with ultrasonic welding, and the cells constitute a strong lateral restraints and stiffness structure by filling with materials such as sand, stone or concrete).

Product Application

It is mainly used in foundation reinforcement, soft foundation treatment, steep slope protection, landslide prevention, load-bearing gravity hybrid wall, and it is especially suit- able for weathered mountain forests, deserts and swamps.

Product Features
  • It is capable of expansion and contraction, and it can be folded dur- ing transportation and stretched during construction. It constitutes a strong lateral restraint and stiffness structure by filling with materials such as sand- stone or concrete.
  • It is formed by light material with stable chemical properties which is resistant to abrasion, photooxidation, acid, and alkali. It is suitable for differ- entsoil and desert conditions.
  • It has a higher lateral limit, anti-skid, and anti-deformation, and can effectively enhance the bearing capacity of the roadbed and load distribu- tion.
  • It can meet different engineering needs by changing height, welding distance, and other geometric dimensions.
  • It is convenient to connect and can improve construction speed.
Geocell Technical Datum
Material Properties Unit Test Method
Cell Depth mm 75 100 150 200
Welding Distance mm 330, 400, 440, 500, 600, 660, 800, 1000
Polymer Density g/cm3 0.935-0.965 ASTM D 1505
Environmental Stress Crack Resistance Hours 5000 ASTM D 1693
Carbon Black Content % 1.5% - 2.0% ASTM D 1603
Nominal Sheet Thickness Before Texturing mm 1.27 -5%,+10% ASTM D 5199
Nominal Sheet Thickness After Texturing mm 1.52-5%,+10% ASTM D 5199
Seam Peel Strength N 1065 1420 2130 2840 EN ISO 13426-1B
Seam Efficiency % 100 GRI-GS13
Nominal Expanded Cell Size (width x length) mm 320x287,475x508 etc
Nominal Expanded Panel Size (width x length) m 2.56x8.35, 4.5x5.0, 6.5x4.5, 6.1x2.44
