Specifications
Material :
Synthetic fibers (polypropylene, polyester)
Supply Ability :
9999999㎡/MONTH
Production Process :
Needling or weaving craftsmanship, ensuring stable structure and excellent performance
MOQ :
1000pcs
Core Functions :
Filtering, drainage, isolation, reinforcement, protection
Certification Standard :
GB/T17638-2017
Key Performance :
Lightweight, high tensile strength, good permeability
Brand Name :
YPEP
Certification :
ISO9001
Packaging Details :
Woven fabric packaging
Alternative Names :
Geotextile, Geotextile Fabric, Geosynthetic Fabric
Place of Origin :
China
Delivery Time :
5 days
Payment Terms :
T/T
Description
High Strength Permeable Geotextile Fabric Woven Nonwoven PP Geosynthetic
Product Details

Geotextile fabric is a high-performance permeable geosynthetic material made of high-quality synthetic fibers through professional needling or weaving processes, playing an indispensable role in modern geotechnical engineering and infrastructure projects. As a key type of geosynthetic new material, it features a cloth-like finished product with flexible dimensions, including a width of 1-9m (the widest in China) and a length of 50-100m, which can be customized according to project needs to meet diverse construction requirements.

Our geotextile fabric is divided into woven and nonwoven types, with rich specifications covering a unit area mass of 100-1000g/㎡. It boasts excellent comprehensive performance: high tensile strength, maintaining sufficient strength and elongation in both dry and wet conditions; strong corrosion resistance, able to withstand long-term use in soil and water with different pH values; good water permeability, thanks to the gaps between fibers that ensure smooth water seepage without clogging; superior properties, free from damage by microorganisms and moths; and easy construction, with light and soft material that facilitates transportation, laying and operation on-site.

Widely applied in water conservancy, electric power, mines, highways, railways and other geotechnical projects, this geotextile fabric serves as an ideal filter material for soil separation, drainage material for reservoirs, mines and high-rise building foundations, anti-scouring material for river dykes and slope protection, reinforcing material for road and airport foundations, anti-frost and anti-freeze insulation material, and anti-cracking material for asphalt pavements, effectively enhancing project stability and extending service life. All products comply with GB/T17638-2017 standard, with reliable quality and stable performance, trusted by engineers and contractors worldwide.

Performance Parameters (GB/T17638-2017)
Item Nominal Breaking Strength (KN/m) 3 5 8 10 15 20 25 30 40
MD & CMD Breaking Strength (KN/m) ≥ - 3 5 8 10 15 20 25 30 40
Elongation of Nominal Breaking Strength (%) 20~100
CBR Bursting Strength (KN/m) ≥ - 0.6 1 1.4 1.8 2.5 3.2 4 5.5 7
Mass Deviation per Unit (%) ±5
Deviation of Width (%) -0.5
Deviation Rate of Thickness (%) ±10
Equivalent Pore Size O90 (mm) 0.07~0.20
Vertical Coefficient of Permeability (cm/s) K*(10⁻¹ ~ 10⁻³), K = 1.0 ~9.9
MD & CMD Tearing Strength (KN) - 0.1 0.15 0.2 0.25 0.4 0.5 0.65 0.8 1
Acid & Alkali Resistance (Strength Retention) (%) 80
Anti-Oxidant (Strength Retention) (%) 80
Item Specification (g/㎡) 100 150 200 300 400 500 600 700 800
Nominal Breaking Strength (KN/m) - 4.5 7.5 10 15 20 25 30 40 50
MD & CMD Breaking Strength (KN/m) ≥ - 4.5 7.5 10 15 20 25 30 40 50
Elongation of Nominal Breaking Strength (%) 40~80
CBR Bursting Strength (KN/m) ≥ - 0.8 1.6 1.9 2.9 3.9 5.3 6.4 7.9 8.5
MD Tearing Strength (KN) ≥ - 0.14 0.21 0.28 0.42 0.56 0.7 0.82 1.1 1.25
Equivalent Pore Size O90 (mm) 0.05~0.20
Vertical Coefficient of Permeability (cm/s) K*(10⁻¹ ~ 10⁻³), K = 1.0 ~9.9
Deviation of Width (%) -0.5
Mass Deviation per Unit (%)

-5
