Corrosion Resistant Screw Bushings For Rubber Particle Modification Production Suitable Spare Parts
Corrosion Resistant Screw Bushings For Rubber Particle Modification Production Suitable Spare Parts
Corrosion Resistant Screw Bushings For Rubber Particle Modification Production Suitable Spare Parts
Corrosion Resistant Screw Bushings For Rubber Particle Modification Production Suitable Spare Parts
Corrosion Resistant Screw Bushings For Rubber Particle Modification Production Suitable Spare Parts
Corrosion Resistant Screw Bushings For Rubber Particle Modification Production Suitable Spare Parts
Specifications
Brand Name :
BLM
Model Number :
standard or customized
Certification :
ISO 9001
Place of Origin :
Jiangsu, China
MOQ :
10pcs
Price :
Negetation
Payment Terms :
T/T,Western Union,MoneyGram
Supply Ability :
according to the customized products
Delivery Time :
60 to 75 days
Packaging Details :
Packing in wooden case
Main Material :
NiCrW alloy (Ni60 based on the addition of CrC and CrB
Product Features :
Wear resistance, corrosion resistance, belongs to the special alloy, hardness in HRC≥57, alloy parent full melt, improve the density, hardness.
Temperature Resistance :
Temperature limit 600℃
Alloy Layer Thickness :
≧1.8mm
Alloy Layer Hardness :
HRC≥57
Advantage :
Elliptic flat angle process
recommendation reason :
New composite liner
Liner Type :
Nickel chrome tungsten composite liner
Application extruder macchine type :
type 75 and above 75 can made by composite liner
Application area :
Plastic manufacturing,food processing ,construction,pharmaceuticals,chemical manufacturing,recycling and so on
Description

Corrosion-Resistant Screw Bushings for Rubber Particle Modification Production Suitable Spare Parts



The extruder bushing is a key accessory installed in a specific part of the extruder. It is usually located inside the barrel and fits closely with the screw. Its main function is to reduce the friction between the screw and the barrel, protect the barrel from wear, ensure that the screw rotates in a stable environment, and achieve efficient material conveying, plasticizing and extrusion processes.
Code No
Description
Materials
Alloy Thickness
Application
BLM-01
Ni-Alloy Liner
Ni-Alloy
5-20mm
Extruder machine
BLM-02
Bimetallic liner
Steel+Ni Alloy
2-3mm
Extruder machine
BLM-03
Steel Liner
Steel
5-20mm
Extruder machine



Corrosion Resistant Screw Bushings For Rubber Particle Modification Production Suitable Spare Parts



Question 1: Does your company have any issues with the inner walls of machine barrels or liners that come into contact with materials being not wear-resistant, and the replacement frequency of threaded components being fast, which seriously affects production efficiency?

Our solution: Using our independently developed alloy material BLM60 (Ni60Tungsten Carbide), the hardness can reach HRC62-64 Mainly used for processing liner or spray welding liner inner walls, for materials and industries that require ultra-high wear resistance.
Why we choose BLM60?
BLM60, the nickel based alloy materials with excellent wear resistance and corrosion resistance have significantly improved compactness; The metallographic structure is more detailed; A significant increase in hard wear-resistant phase carbides! Thus achieving twice the wear resistance of vacuum sintered alloys; The alloy layer has been changed from an 8-shaped alloy layer to a waist shaped elliptical 8-shaped alloy layer! Sharp corners provide better wear resistance and support.
(The wear resistance test shown in the following figure)

Corrosion Resistant Screw Bushings For Rubber Particle Modification Production Suitable Spare Parts

Corrosion Resistant Screw Bushings For Rubber Particle Modification Production Suitable Spare Parts

Corrosion Resistant Screw Bushings For Rubber Particle Modification Production Suitable Spare Parts
