RS- 775 Motor 3500-12000RPM 12 Volt DC Permanent Magnet Motor High Power For Electrical Tools
RS- 775 Motor 3500-12000RPM 12 Volt DC Permanent Magnet Motor High Power For Electrical Tools
RS- 775 Motor 3500-12000RPM 12 Volt DC Permanent Magnet Motor High Power For Electrical Tools
RS- 775 Motor 3500-12000RPM 12 Volt DC Permanent Magnet Motor High Power For Electrical Tools
RS- 775 Motor 3500-12000RPM 12 Volt DC Permanent Magnet Motor High Power For Electrical Tools
RS- 775 Motor 3500-12000RPM 12 Volt DC Permanent Magnet Motor High Power For Electrical Tools
RS- 775 Motor 3500-12000RPM 12 Volt DC Permanent Magnet Motor High Power For Electrical Tools
RS- 775 Motor 3500-12000RPM 12 Volt DC Permanent Magnet Motor High Power For Electrical Tools
Specifications
Motor Type :
18v High power dc carbon brush motor
Bearing selection :
oil bearing ,ball bearing or Customizated
Voltage :
6v-36v
Shaft diameterφ5mm or Customized :
φ5mm or Customizated
Magnet :
Strong
Brand Name :
Masing Motor
Model Number :
MSRS-775/RS-770
Certification :
16949,RohS,CE,ISO
Place of Origin :
China
MOQ :
5000
Price :
Negotiable
Payment Terms :
T/T
Supply Ability :
1000000piece/per month
Delivery Time :
3-5 work weeks
Packaging Details :
Carton box
Structure :
Totally Enclosed
Brush Type :
Carbon brush
Product Name :
RS-775 high speed permanent magnet motor
Motor diameter :
φ42mm or Customizated
direction of motor :
cw & ccw available
Description
RS-775 Motor 3500-12000RPM 12 Volt DC Permanent Magnet Motor
High power DC motor designed for electrical tools and electric fans with customizable specifications and reliable performance.
Product Overview
  • Widely used in electrical tools, electric fans, robots, power tools, automobile actuators, vacuum pumps, water pumps, small electric drills, and smart home applications
  • Voltage range: 6V-36V
  • Speed: 2000-20000 RPM
  • Constant rotating speed with customization available
  • Motor size: φ42mm×60mm or φ42mm×67mm
  • Suitable for small diameter, low noise, and high torque applications
  • Shaft diameter: φ5mm or customized
  • Shaft type: D-cut, flat, round, with hole, threaded hole, threaded shaft or customized
  • Motor direction: CW & CCW available
  • EMC compliant
  • Built-in cooling fan and varistor
  • Compatible with wheel attachments
  • Working temperature: -40°C to +60°C
  • Samples available for testing
  • Bearing type: Oil bearing or ball bearing
  • 100% quality inspection before shipment
  • OEM and ODM services supported
Technical Specifications
  • Speed: 3000-25000 RPM
  • Continuous Current: 50mA-800mA
  • Efficiency: Customized 65%-85%
  • Type: 42MM Permanent Magnet Brushed DC Motor
  • Torque: 0.5-2kgf.cm or customized
  • Construction: Permanent Magnet
  • Commutation: Carbon Brush
  • Protection: Totally Enclosed
  • Noise: ≤60DB Low noise
  • Power: 1W-100W High Power
  • Certification: 16949, CE, ROHS, ISO
  • MOQ: 5000 Pieces
Product Images
RS- 775 Motor 3500-12000RPM 12 Volt DC Permanent Magnet Motor High Power For Electrical Tools RS- 775 Motor 3500-12000RPM 12 Volt DC Permanent Magnet Motor High Power For Electrical Tools
Performance Data
RS- 775 Motor 3500-12000RPM 12 Volt DC Permanent Magnet Motor High Power For Electrical Tools
MODEL VOLTAGE NO-LOAD AT MAXIMUM EFFICIENCY STALL
OPERATING RANGE NOMINAL SPEED CURRENT SPEED CURRENT TORQUE OUTPUT EFF TORQUE CURRENT
JRS-775SH-4050 9~18 12 6500 0.5 5400 2.5 350 19.4 64.5 2080 12
JRS-775PH-8017 6~20 18 19800 2.3 16320 18.8 1406 235.7 69.5 8000 96
Packaging & Delivery
  • Packaging: Strong Carton 100pcs/box, or customized
  • Port: Shenzhen/Guangzhou/Shanghai
  • Selling Units: Single item
  • Package size: 37×27×24cm
  • Gross weight: 0.035kg
  • Supply Ability: 100,000 pieces per month
Lead Time
Quantity (pieces) 1 - 100 101 - 1000 > 5000
Lead Time (days) 10 15 To be negotiated
Samples
  • Maximum order quantity: 1 piece
  • Sample price: $5/piece
Certifications
RS- 775 Motor 3500-12000RPM 12 Volt DC Permanent Magnet Motor High Power For Electrical Tools
Factory & Applications
RS- 775 Motor 3500-12000RPM 12 Volt DC Permanent Magnet Motor High Power For Electrical Tools RS- 775 Motor 3500-12000RPM 12 Volt DC Permanent Magnet Motor High Power For Electrical Tools RS- 775 Motor 3500-12000RPM 12 Volt DC Permanent Magnet Motor High Power For Electrical Tools
Applications include: Driverless technology, Artificial intelligence, Intelligent transportation, Health care, Smart city, Automotive supplies, Security monitoring, 5G communication, and Smart home.
Frequently Asked Questions
Q1: Are you a trading company or manufacturer?
A1: We are a manufacturer with 10 years of experience in producing micro motors.
Q2: Can you send me a price list?
A2: All of our motors are customized based on different requirements like torque, voltage, and shaft specifications. Price varies according to annual quantity. Please send us detailed requirements and annual quantity for a quick quotation.
Q3: How to confirm requirements before mass production?
A3: We can provide samples according to your drawings or technical requirements. Mass production will only start after your confirmation. Alternatively, send us your samples and we will create our own sample according to your requirements.
Q4: How do you guarantee product quality?
A4: We check products after each manufacturing process and perform 100% inspection before shipment.
Q5: How do you maintain long-term business relationships?
A5: We maintain good quality and competitive pricing to ensure customer benefits. We respect every customer and sincerely conduct business while building friendships.
Q6: What's your minimum order quantity?
A6: The minimum quantity is usually 5,000 pieces.
