| Main Frame | Clear-span Width: From 3m to 70m, length is no limit |
| Structure | Material: Hard Pressed Extruded Aluminum Alloy 6061-T6& 6082-T6 |
| Cover material | Density: 650g/sqm, 750g/sqm, 850g/sqm |
| Material: Both sides lacquered PVC coated fabric | |
| Features: UV Resistant, Waterproof, Fire RetardantB1 | |
| Sidewall | PVC Wall, Glass Wall, ABS Wall, Sandwich Wall |
| Wind Load | 80km/h - 120km/h |
| Snow Load | 10cm Thickness Floating Snow |
| Temperature Index | -30 Degree Celsius to +70 Degree Celsius |
| Life Time | Aluminum frame more than 15 Years. PVC fabric 5-10 years |
| Certification | SGS,ISO 9001:2008,IAF.NAC |
| Span(width) | Side height | Ridge height | Longest part | Main profile(mm) | Bay distance |
| 3m | 2.5m | 3m | 2.7m | 36*71*2.5 | 3m |
| 6m | 2.5m | 3.5m | 3.2m | 48*84*3 | 3m |
| 8m | 2.5m | 3.9m | 4.3m | 48*84*3 | 3m |
| 9m | 2.5m | 4.1m | 4.8m | 48*84*3 | 3m |
| 10m | 2.5m | 4.3m | 5.3m | 48*84*3/48*100*3 | 3m |
| 12m | 3m | 5m | 6.3m | 68*122*3 | 5m |
| 15m | 3m | 5.4m | 7.9m | 108*150*3 | 5m |
| 18m | 3m | 5.9m | 9.5m | 112*203*4 | 5m |
| 20m | 4m | 7.2m | 10.6m | 112*203*4 | 5m |
| 25m | 4m | 8m | 10.6m | 112*203*4 | 5m |
| 30m | 4m | 8.8m | 10.6m | 113*259*5 | 5m |
| 35m | 4m | 9.6m | 10.6m | 120*300*5 | 5m |
| 40m | 4m | 10.5m | 11.1m | 120*300*5 | 5m |
| 45m | 4m | 11.3m | 11.1m | 128*350*5 | 5m |
| 50m | 4m | 12.2m | 11.1m | 128*350*5 | 5m |
| The length can be extended by 3m such as 6m,12,18m,30m... or by 5m bay such as 15m,20m,30m,40m... Customized size or shape is available | |||||
Lighting:
Heating and Cooling:
Flooring:
Furniture:
Decor:
Entertainment:
Catering and Serving:
Safety and Convenience:
Signage:
Power and Connectivity:
Privacy and Partitioning:
Themed Accessories:
Seating Enhancements:
Outdoor Elements:
Utility and Storage:
Material Selection:
Frame Fabrication:
Fabrication of Canopy and Sidewalls:
Event Planning:
Delivery and Setup:
Accessories and Decor:
Logistical Support:
Safety and Compliance:
On-Site Management:
Event Duration:
Dismantling and Cleanup:
Customization:
Consultation and Guidance:
