Specifications
Brand Name :
JC MARINETIME
Model Number :
3 / 4 / 8 / 12 STRAND ROPE
Certification :
ISO / CE
Place of Origin :
CHINA
MOQ :
220 Meter
Price :
30 USD Per Meters
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
50000 Meters Per Month
Delivery Time :
5-20 days
Packaging Details :
Pallet Or As Required
Part :
Dock Mooring
Coil length :
220m
Weight and length tolerance :
± 5%
Spliced strength :
±10% lower
U.V.Resistance :
Very Good
Service :
OEM/ODM
Warranty :
12 Months
Length :
As customer's need,Custermized,220m,As required
Material :
polypropylene,Nylon,polyester,PP,PET/PA/PP/PE as request
Usage :
mooring hawser,anchor rope,mooring tail,mooring rope,Package/mooring/towing/fishing
Packing :
Coil,reel,reel/hunks/bundles/coil,PP Woven Bag,Bundle
Description

3 Strands Twisted Rope Polyester Tire Line Fishing Wire Packing Rope

1.General Description

QINGDAO JINCHENG MARITIME mooring rope series includes nylon, polypropylene filament, polypropylene, polypropylene/polyester blend, polyester and other varieties, which are widely used, with high strength, low elongation, wear resistance, corrosion resistance and other advantages, soft and smooth, easy to operate, and can also be used to make special anti-static ropes. The products are mainly used in ships, fishing, port loading and unloading, power construction, oil exploration, sports goods, national defense research and other fields.

PP 3 Strands Twisted Rope Polyester Tire Line Fishing Wire Packing Rope With 220m Coil Length

2. Main performance

Material Polyamide
Multifilament		 Polyamide
Yarn		 Polypropylene
Multifilament		 Polypropylene Polyester Polypropylene and
Polyester Mixed
Spec.Density 1.14
no floating		 1.14
not floating		 0.91
no floating		 0.91
Floating		 1.27
no floating		 0.95
Floating
Melting Point 215℃ 215℃ 165℃ 165℃ 260℃ 165℃/260℃
Abrasion Resistance Very Good Very Good Medium Medium Good Good
U.V.Resistance Very Good Very Good Medium Medium Good Good
Temperature resistance 120℃max 120℃max 70℃max 70℃max 120℃max 80℃max
Chemical resistance Very Good Very Good Good Good Good Good

3.Technology Comparison

Coil length: 220m

Spliced strength:± 10% lower

Weight and length tolerance:± 5%

MBL=Minimum Breaking Load conform ISO 2307

Other sizes available upon request

PP 3 Strands Twisted Rope Polyester Tire Line Fishing Wire Packing Rope With 220m Coil Length

4.Parameter Table

Specification
规格		 PA Multifilament
锦纶复丝		 PAYarn
锦纶		 PP Multifilament
丙纶长丝		 Polypropylene
丙纶		 Polyester
涤纶		 PET/PP Mixed
丙纶/涤纶混合绳
Dia. Cir Ktex KN Ktex KN Ktex KN Ktex KN Ktex KN Ktex KN
直径 圆 周 线密度 破断强力 线密度 破断强力 线密度 破断强力 线密度 破断强力 线密度 破断强力 线密度 破断强力
4 1/2 10 3.7 10 2.6 6.3 2.3 6 2.1 12 2.9 7.0 2.8
6 3/4 22 7.9 22 6 18 6.5 17 5.9 27 5.6 17.5 6.8
8 1 40 13.8 40 10.9 32 11.4 30 10.4 48 10.0 31 11.9
10 1-1/4 62 21.2 62 15.7 47 16.8 45 15.3 76 15.6 48.5 18.2
12 1-1/2 89 30.1 89 24.1 68 23.9 65 21.7 110 22.3 69.9 25.7
14 1-3/4 121 40.0 121 33.0 95 32.9 90 29.9 148 31.2 95.1 34.7
16 2 158 51.9 158 42.5 121 40.7 115 37.0 195 39.8 124 44.8
18 2-1/4 200 64.3 200 53.9 155 51.9 148 47.2 245 49.8 157 56.1
20 2-1/2 247 79.2 247 66.7 189 62.6 180 56.9 303 62.3 194 68.7
22 2-3/4 299 94.0 299 80.4 231 75.0 220 68.2 367 74.7 235 82.1
24 3 355 112 355 93.6 273 87.7 260 79.7 437 89.6 279 96.3
26 3-1/4 417 129 417 111.5 320 101 305 92.2 512 105 328 113
28 3-1/2 484 149 484 127 373 115 355 105 594 120 380 130
30 3-3/4 555 169 555 143 425 132 405 120 682 134 437 148
32 4 632 192 632 161 483 146 460 132 778 154 497 167
36 4 - 1/ 2 800 240 800 200 614 182 585 166 982 190 629 210
40 5 987 294 987 241 756 221 720 201 1215 235 776 257
44 5-1/2 1190 351 1190 289 924 266 880 242 1468 275 939 308
48 6 1420 412 1420 338 1092 308 1040 280 1750 329 1110 364
52 6-1/2 1670 479 1670 393 1281 357 1220 325 2050 384 1320 424
56 7 1930 550 1930 450 1491 408 1420 371 2380 439 1520 489
