Anti Collision Marine Pneumatic Rubber Fender Length 0.5 - 9.0m Less Reverse Impact
Anti Collision Marine Pneumatic Rubber Fender Length 0.5 - 9.0m Less Reverse Impact
Anti Collision Marine Pneumatic Rubber Fender Length 0.5 - 9.0m Less Reverse Impact
Anti Collision Marine Pneumatic Rubber Fender Length 0.5 - 9.0m Less Reverse Impact
Anti Collision Marine Pneumatic Rubber Fender Length 0.5 - 9.0m Less Reverse Impact
Anti Collision Marine Pneumatic Rubber Fender Length 0.5 - 9.0m Less Reverse Impact
Specifications
Brand Name :
FLORESCENCE
Model Number :
FL rubber fender(36)
Certification :
CCS,ABS,DNV,LR,ISO9001
Place of Origin :
Shandong,China
MOQ :
Negotiable
Price :
Negotiable
Payment Terms :
Western Union, L/C, T/T
Supply Ability :
100 pcs/month
Delivery Time :
5-10 work days
Packaging Details :
nude,container
Length :
from 0.5-9.0m
Initial pressure :
0.05-0.08Mpa
Warranty period :
24 months
Design using life :
Usually 10 years
Product name :
Marine rubber fender
Color :
Black,white,grey
Description

Used For Anti-Collision With Pneumatic Marine Yokohama Rubber Fender

Advantages of FL floating rubber fender:
* Absorb more energy,less reverse impact on the ships
* More flexible ,easy installation
* Durable, practical and economical
* Good quality have been checked by many buyers
* Optional tire and chain,can provide chain with hot galvanizing or stainless steel(304,312,316)
* Optional end fittings for the better suitable of applications

Application of FL rubber fender:
FL pneumatic rubber fender has widespread application as following:
* Ship to ship,ship to wharf
* Oil tankers, container vessels
* Luxury yachts, ocean platforms
* Larges shipyards
* Fender system
* Military ports ,warship
* Larger under water foundations of bridges, etc

Technical performance of marine rubber fender

Specification
DXL(m)

0.05Mpa(Initial pressure 0.05Mpa)(Initial pressure 0.08Mpa)
Weight(kg)Reaction force(KN)

GEA
(KJ)

Weight
(kg)

Reaction force(KN)

GEA
(KJ)

0.5X1.025674625858
0.6X1.032748329811
0.7X1.550137175018024
1.0X1.580182328023945
1.0X2.01002574512533863
1.2X2.01202976316539088
1.35X2.5165427102226561142
1.5X3.0315579153370761214
1.7X3.0405639191436840287
2.0X3.55908753086321150430
2.5X4.01050138166311101815925
2.5X5.513332019943141026531317
3.0X5.0188020001050215527091571
3.0X6.0216024881312247032921888
3.3X4.5202018841175230024761640
3.3X6.0230027831675260036522338
3.3X6.5270030151814308039612532
3.3X10.6440352573067502069074281
4.5X9.0655457474752747075516633
4.5X128739798464739960104909037
Note:The weight is the fender body weight(without tires and chain),with weight error of ±10% and counterforce error of ±10%


Storage of FL rubber fender

* When not using for a long time,wash the surface of the fender,dry up and fill in sufficient right amount of compressed air to lay them in a cool.dry and well-ventilated place.

* The storage place of pneumatic rubber fender should be far away from hear source

* Try to keep fender away from acid,alkali,grease and organic solvents

* When not applying the fenders,the pneumatic rubber fender can’t be piled up and heavy items can’t be piled on the fender

Anti Collision Marine Pneumatic Rubber Fender Length 0.5 - 9.0m Less Reverse Impact

Anti Collision Marine Pneumatic Rubber Fender Length 0.5 - 9.0m Less Reverse Impact

Anti Collision Marine Pneumatic Rubber Fender Length 0.5 - 9.0m Less Reverse Impact
