Specifications
Brand Name :
OUCO
Model Number :
OUCO-MW-50
Certification :
CCS.ABS.LRS.BV.GL.DNV.NK
Place of Origin :
China
MOQ :
1 set
Price :
negotiation
Supply Ability :
100 sets per year
Delivery Time :
60 days
Packaging Details :
Shipping Container/Wood Crate/nude
Color :
Customer Requirement
Chain diameter :
12mm to 82mm
Capacity :
Customized
Certificate :
CCS.ABS.LRS.BV.GL.DNV.NK
Product Name :
OUCO World Widely Used Hydraulic Electric Anchor Winch With Certificates
Description

OUCO World Widely Used Hydraulic Electric Anchor Winch With Certificates


Product Description

Windlass is mainly composed of a base, bracket, chain wheel, sprocket wheel, brake, gear box, control system (excl. hand windlass) etc., electric windlass motor, hydraulic windlass hydraulic pumping station. The main technical indexes of windlass include chain diameter, anchor nominal speed, rated load, load, a few transmission, electric system. Windlass on the ship anchor chain and sprocket installation to ensure the wrap angle of 117 - 120 degrees.

Product Feature

Anchor machine widely used in the shipbuilding industry, for ship anchor, anchor cable with machinery and equipment.

Genernal Arrangement
Customized Capacity Marine Deck Winches , Hydraulic Electric Boat Anchor Winch
Technical Parameters

Name Chain Dia Working Load Supporting Load

Working

Speed

Warping

Load

 Motor Power
(mm) (kN) (kN) (kW)
Electric Hydraulic
Electric Anchor Windlass 12.5 5.9 30 ≥9 5 3/1.2
Electric (Hydraulic) Anchor Windlass 14/16/17.5 8.3/10.9/13.0 51/67/80 ≥9 8 4.3/1.7 5.5
19/20.5/22 15.3/17.9/20.6 95/110/126 ≥9 10 8.5/3.5 7.5
24/26 24.5/28.7 149/175 ≥9 20 8.5/3.5 11
28/30 33.3/38.3 202/231 ≥9 30 11/11/7.5 15
32/34/36 43.5/49.1/55.1 261/294/329 ≥9 30 16/16/11 22
38/40/42 61.4/68.0/75.0 365/402/442 ≥9 40 22/22/16 30
44/46/48 82.3/89.9/97.9 483/526/570 ≥9 50 30/30/22 37
50/52/54 106.3/114.9/123.9 617/664/713 ≥9 50 30/30/22 45
56/58/60 133.3/143.0/153 764/816/870 ≥9 60 45/45/30 55
62/64 163.4/174.1 925/982 ≥9 80 45/45/30 55
66/68 185.1/196.5 1040/1098 ≥9 100 45/45/30 75
70/73 208.3/226.5 1160/1254 ≥9 100 60/60/45 75
76/78 245.5/258.6 1350/1416 ≥9 125 60/60/45 90
81/84 311.7/335.2. 2171/2320 ≥9 140 75/75/36 110
87/90 359.5/384.8 2473/2629 ≥9 150 75/75/36 120
92/95 402.0/428.7 2735/2898 ≥9 200 85/85/64 130
97/100 446.9/475.0 2995/3162 ≥9 250 100/100/150 150
105/107 523.7/543.8 3612/3750 ≥9 300 110/110/55 180
112/114 595.8/617.3 4109/4428 ≥9 350 132/132/66 200



Customized Capacity Marine Deck Winches , Hydraulic Electric Boat Anchor Winch

Customized Capacity Marine Deck Winches , Hydraulic Electric Boat Anchor Winch

FAQ
1.Your need quantity?(Set)
2.FOB price or CIF price?(If need CIF price,kindly tell us your nearest sea port)
3.Driven type?(Electric or Hydraulic or Diesel)
4.Working loading capacity?(Ton) or Pull force?(KN)
5.Working speed?(m/min)
6.Rope diameter?(mm)
7.Rope capacity?(m)
8.Power supply?(Voltage---50Hz/60Hz---3Phase)
9.Any other special requirements?
