Double Drum Marine Deck Winches 50T Large Torque Low Noise Running Smoothly
Double Drum Marine Deck Winches 50T Large Torque Low Noise Running Smoothly
Double Drum Marine Deck Winches 50T Large Torque Low Noise Running Smoothly
Double Drum Marine Deck Winches 50T Large Torque Low Noise Running Smoothly
Double Drum Marine Deck Winches 50T Large Torque Low Noise Running Smoothly
Double Drum Marine Deck Winches 50T Large Torque Low Noise Running Smoothly
Double Drum Marine Deck Winches 50T Large Torque Low Noise Running Smoothly
Double Drum Marine Deck Winches 50T Large Torque Low Noise Running Smoothly
Specifications
Brand Name :
OUCO
Model Number :
OUCO-MW-50
Certification :
CCS.ABS.LRS.BV.GL.DNV.NK
Place of Origin :
China
MOQ :
1 set
Price :
negotiation
Supply Ability :
100 sets per year
Delivery Time :
60days
Packaging Details :
Shipping Container/Wood Crate/nude
Color :
Customer Requirement
Power Source :
Electric
Application :
Boat
Certificate :
CCS.ABS.LRS.BV.GL.DNV.NK
Size :
Customized Size
Product Name :
OUCO 50T Double Drum Electrical Diesel Hydraulic Marine Mooring Winch Air Operation
Description

OUCO 50T Double Drum Electrical Diesel Hydraulic Marine Mooring Winch Air Operation

Product Description

OUCO 50T Double Drum Electrical Diesel Hydraulic Marine Mooring Winch Air Operation can be designed to electric or hydraulic winch,single drum or double drum,multiple drum according to customer's needs.
Electric mooring winch is widely used in the place with heavy work and big traction.the motor of the single drum winch drive the drum by reducer box,the brake is installed between the motor and input shaft. electric mooring winch could be set up to single drum, double drum and multiple drum for adapting the needs of hoisting, traction and rotary work. Normally,winch with the rated load less than 10ton could be set up to electric mooring winch.
Hydraulic mooring winch is the winch with the rated load from 10T~5000T, hydraulic motor have high mechancial efficiency and large torque, can drive different distributor as per different working conditions. this kind of winches have following features:compact structure,small size,light,nice appearance,safty,high efficiency,large torque,good stability,low noise,reliable operation and so on.

Product Feature

It is an unstandard products. We can make and design as per customer's requirement.

Genernal Arrangement
Double Drum Marine Deck Winches 50T Large Torque Low Noise Running Smoothly
Technical Parameters

Name
Rated Pull
Rated Speed
Drum Capacity
Motor Power(KW)
(KN)
(m/min)
(m)
Electric
Hydraulic
Electric (Hydraulic) Mooring Winch
5
≥12
φ8×100
3/1.2
---
10
≥12
Φ10×150
4.3/1.7
5.5
20
≥12
Φ15×150
8.5/3.5
11
30
≥15
Φ17×150
11/11/7.5
---
40
≥15
φ18×150
16/16/11
22
50
≥15
φ20.5×180
22/22/16
30
75
≥15
φ26×200
30/30/22
45
80
≥15
φ26×200
30/30/22
100
≥15
φ30×200
45/45/30
45
125
≥15
φ30×200
45/45/30
160
≥15
φ32×250
60/60/45
75
200
≥9.6
φ41×250
45/45/30
75
250
≥9.6
φ44.5×250
60/60/45
90
315
≥7.8
φ522×250
60/60/45
90
400
≥7.8
φ56×250
85/85/64
110
500
≥7.8
φ58×250
85/85/64
110
560
≥6
φ64×250
85/85/64
132
650
≥6
φ70×250
85/85/64
132
1000
≥4
φ85×250
85/85/64
132
1200
≥4
φ95×250
120/120/90
160
1500
≥4
φ95×250
150/150/72
200
1800
≥4
φ95×250
150/150/72
250
2000
≥4
φ100×250
180/180/270
270



Double Drum Marine Deck Winches 50T Large Torque Low Noise Running Smoothly

Double Drum Marine Deck Winches 50T Large Torque Low Noise Running Smoothly

FAQ
1.Your need quantity?(Set)
2.FOB price or CIF price?(If need CIF price,kindly tell us your nearest sea port)
3.Driven type?(Electric or Hydraulic or Diesel)
4.Working loading capacity?(Ton) or Pull force?(KN)
5.Working speed?(m/min)
6.Rope diameter?(mm)
7.Rope capacity?(m)
8.Power supply?(Voltage---50Hz/60Hz---3Phase)
9.Any other special requirements?
