Two Ropes Clamshell Grab Bucket For Loading / Unloading Scrap Materials
Two Ropes Clamshell Grab Bucket For Loading / Unloading Scrap Materials
Two Ropes Clamshell Grab Bucket For Loading / Unloading Scrap Materials
Two Ropes Clamshell Grab Bucket For Loading / Unloading Scrap Materials
Two Ropes Clamshell Grab Bucket For Loading / Unloading Scrap Materials
Two Ropes Clamshell Grab Bucket For Loading / Unloading Scrap Materials
Two Ropes Clamshell Grab Bucket For Loading / Unloading Scrap Materials
Two Ropes Clamshell Grab Bucket For Loading / Unloading Scrap Materials
Specifications
Brand Name :
OUCO
Model Number :
OUCO-MCG-2
Certification :
ISO9001
Place of Origin :
China
MOQ :
1 set
Price :
negotiation
Payment Terms :
L/C, T/T
Supply Ability :
150 sets per year
Delivery Time :
1 month
Packaging Details :
Shipping Container/Wood Crate/nude
Color :
As Requirement
CM3 :
As Requirement
Material :
Steel
Condition :
New
Peel :
2 peels
Description

OUCO Two Ropes Mechanical Sand Clamshell Grab Bucket Manufacturer

Product Description

The Two Rope Mechanical Clamshell grabs for two line operated cranes (One Holding Rope and One closing Rope). The grabs are specially designed for charging and discharging sand, gravel and other bulk materials. The grabs can be executed with open or closed shells depending on the job and the type of material to be handled. The grabs are manufactured of high wear resistant steels. All bearings are heavy duty and sealed for high performance.

Product Feature

1. Optional the Grabs shells can be executed with Kick plates to reduce capacity.

2. This will give you an advantage when bulk materials with various densities are (dis)charged.

3. This can be calculated to the biggest capacities possible in combination with the lifting capacity of your crane.

Technical Parameters

Two Ropes Clamshell Grab Bucket For Loading / Unloading Scrap Materials

Model 2Dxx-xx

Lifting Weight

(t)

 2.5 3.0 3.0 3.0 3.0 3.0 5.0 5.0 5.0 5.0 5.0 6.0 8.0 8.0 8.0 10 10 10

Grab Weight

(t)

 1.01 1.49 1.15 1.46 1.46 1.70 2.38 2.38 2.0 2.25 2.20 2.22 3.94 3.7 3.64 4.9 4.60 4.36

Grab Volume

(m³)

 0.7 1.0 1.1 1.5 1.7 2.0 1 1.6 1.8 2.5 2.7 2.5 1.6 3.0 4.0 2.0 3.4 5.0
Load Capacity(t) 1.4 1.5 1.85 1.54 1.54 1.31 2.6 2.6 3.0 2.75 2.8 4.0 4.0 4.3 4.36 5.1 5.4 5.64
Fulls 5 5 3 3 3 3 5 5 4 3 4 5 5 5 3 5 5 3
A(m) 1.03 1.18 1.20 1.30 1.35 1.45 0.97 1.40 1.50 1.50 1.62 1.40 1.80 1.65 1.81 1.60 1.78 2.01
B(m) 1.65 1.95 2.05 2.24 2.24 2.28 2.42 2.40 2.26 2.56 2.42 2.48 2.20 2.75 3.00 2.50 2.94 3.20
C(m) 1.82 2.37 2.35 2.84 2.84 2.60 2.76 2.76 3.04 3.04 3.04 3.01 2.70 3.13 3.53 2.65 3.18 3.90
D(m) 1.78 2.62 2.74 2.89 2.89 2.80 3.15 3.15 3.18 3.28 3.25 3.30 3.90 4.29 4.05 3.92 4.30 4.30
E(m) 1.66 2.11 2.26 2.38 2.37 2.25 2.54 2.54 2.66 2.67 2.82 2.62 2.98 3.29 3.45 2.99 3.31 3.55

Wire Rope Diameter

Φ(mm)

 17.5 16.0 17.5 17.5 17.5 17.5 18.5 18.5 18.5 18.5 18.5 19.5 25.5 25.5 25.5 28.5 28.5 28.5

Pulley Diamrter

Φ(mm)

244

300

300

350

 400 400 400 400 420 420 420 420 420 360 500 500 500 500 500 500

Product Details

Two Ropes Clamshell Grab Bucket For Loading / Unloading Scrap Materials

Two Ropes Clamshell Grab Bucket For Loading / Unloading Scrap Materials

FAQ

1. Q:In the material, how should we choose and determine?
A:The selection of the material of the grab edge plate, generally speaking, is the use of high strength wear-resistant steel plate.
2. Q:Electric grab, its use in the process should pay attention to what aspects?
A:In use process, should pay attention to the wire rope and the important parts, because, if the improper use of words, then, the prone to breakage, so we must have enough attention.
3. Q:Which is an important way to improve service life?
A:The important way to improve the service life of the grab bucket is to improve the abrasion resistance of the grab pin and shaft sleeve, and to improve the abrasion resistance of the blade of the bucket body.
4. Q: The type of grab and its span size, whether will affect the grab price?
A:The type of grab, such as the hook or double hook, will affect the price of the grab, because the type is different, then the corresponding price is also different. As for the span of the grab, it is also one of the factors affecting the price of the grab, so it will certainly have an impact.
