Specifications
Brand Name :
Makinopc
warranty :
1 Year
Immunity :
EN50082-2 standard
video outgoing-inspection :
Not Available
Product Name :
Emergency stop electronic handwheel
material :
Cast Iron
Price :
$65-75 / piece
Warranty :
12 months
MOQ :
1 piece
style :
Solid
Cable :
Static 1.6 meters, straighten 5.5 meters oil resistant spiral wire
Adsorption Method :
With strong magnetic adsorption
Place of Origin :
Guangdong, China
Band switch :
ALPS, Axis selection OFF XYZ456, multiplier X1 X10 X100
weight (kg) :
1
machinery test report :
Not Available
Size :
141*73*31(mm)
LED Visible Indicator :
Green color
Product Model :
MS-5V-100PPR, MS-12V-25PPR, MS-24V-100PPR
Core Components :
Photoelectric all-metal pulse
Description
Product descriptions from the supplier

MS-5V-100PPR: Signal (A B,-A -B), Voltage (5v), Pulse (100PPR) (R) Suitable for Fanuc, Weihong, Guangshi, , Fagor, Cairndi and other systems.

MS-12V-25PPR: Signal (A B), Voltage (5-12v), Pulse (25PPR) Suitable for Mitsubishi and other systems.

MS-24V-100PPR: Signal (A B), Voltage (5-26v), Pulse (100PPR) Suitable for PLC and other systems.

Note: Currently on the market can see the system, this handwheel are applicable.

Special Note: Encoder use voltage DC5-24V (such as Mitsubishi system for DC12V,). Other systems such as wide number / Fanuc / / Fagor for DC5V, PLC control for 24V. ) Connect the wrong voltage or connect the wrong line will lead to encoder burn out, please note.

Makinopc MS Solid Cast Iron Electronic Handwheel 6 Axis 5V 12V 24V 100PPR Emergency Stop Fanuc Syntec Mitsubishi Systems
Makinopc MS Solid Cast Iron Electronic Handwheel 6 Axis 5V 12V 24V 100PPR Emergency Stop Fanuc Syntec Mitsubishi Systems
Makinopc MS Solid Cast Iron Electronic Handwheel 6 Axis 5V 12V 24V 100PPR Emergency Stop Fanuc Syntec Mitsubishi Systems
About this supplier

Shenzhen Muye Precision Control Electromechanical Co., Ltd., established in 2014, specializes in CNC machine tool accessories and components. With 11-50 employees, it offers products compatible with FANUC, , MITSUBISHI, and other systems. The company provides integrated solutions and supports customization, ensuring quality and reliability in automation equipment.
