Specifications
Brand Name :
ZT
Model Number :
8-layer Semi-Automatic Drawer Type Magnetic Separator
Certification :
ISO9001：2008
Place of Origin :
FOSHAN，GUANGDONG，CHINA
MOQ :
1set
Price :
Negotiable
Delivery Time :
Within 25 days after the advance payment is made
Packaging Details :
Film And Wooden Case
Payment Terms :
T/T, Western Union
Supply Ability :
50 SETS PER MONTH
Voltage :
220V/380V
Condition :
New
After-sales service provided :
Video technical support,Online support
Warranty :
1 Year
Type :
Magnetic Separator
Weight :
1.2-5.1T
Production capacity :
High level
Power(w) :
2.2-37 kw
Application :
pyrrhotite,magnetic separator,Ore/iron/sand,slag plant
Capacity :
1.5~7.5 t/h
Magnetic intensity :
12000~15000 GS
Description

Reliable Permanent Rod Magnetic Separation Equipment Drawer Type

Destination

Designed for high-performance magnetic separation of bulk materials with fraction of size up to 5 mm, without stopping of the technological process.

Design features of the separator

  • Mounted on vertical pipes and in the places of product discharge.
  • The number of magnetic units can range from 7 to 23 pcs, depending on the productivity and properties of the product to be separated.
  • Cleaning of the separator is carried out in the automatic mode according to the designated cyclogram.
  • Magnetic block is arranged on the principle of pneumatic piston. Magnetic system in form of a rod together with the magnets is moved inside the tube under the action of compressed air.
  • Components with high performance of leading world companies are used.

Principle of function

The initial product with tested capacity is fed into the working area of the separator, depositing ferromagnetic impurities on the surface of the magnetic rods. Cleaning of the separator is carried out automatically, by moving the magnetic blocks from the working area to the cleaning zone by means of compressed air.

Applications:

  • Coal Industries
  • Abrasive Industries
  • Chemical Industries
  • Paper and Pulp Industries
  • Ceramic Industries
  • Rubber Industries
  • Petroleum Industries
  • Animal Feed Industries
  • Recycling Industries
  • Mineral Processing
