High-Speed CNC Turned Graphite Electrode with ±0.002~0.005mm Tolerance and ISO9001 Certified Precision Machined Components
High-Speed CNC Turned Graphite Electrode with ±0.002~0.005mm Tolerance and ISO9001 Certified Precision Machined Components
High-Speed CNC Turned Graphite Electrode with ±0.002~0.005mm Tolerance and ISO9001 Certified Precision Machined Components
High-Speed CNC Turned Graphite Electrode with ±0.002~0.005mm Tolerance and ISO9001 Certified Precision Machined Components
Specifications
Brand Name :
IMission
Model Number :
CNC Turning
Certification :
ISO9001
Place of Origin :
China
MOQ :
I PC
Price :
0.1~5USD
Payment Terms :
L/C,D/A,D/P,T/T,Western Union,MoneyGram
Supply Ability :
10000pcs per month
Delivery Time :
7~35 working days
Packaging Details :
Bubble and Carton or Customization
Material :
Aluminum
Weight :
0.1-8kg
Service :
OEM or ODM
Key Word :
CNC Turning Parts
Shipping Method :
Express, Air, Sea, Etc.
Product Process :
CNC Turning
Quality :
100% Inspection
Our Service :
24 Hours Online
Feature :
Durable And High Precision
Surface Finishing :
Anodizing, Plating, Polishing, Etc
Processing :
CNC Machining, CNC Milling, CNC Turning,Stamping...
Drawing :
IGES(igs), STEP(stp), SolidWorks (sodprt), PRT, AutoCad,PDF or Samples
Highlight :
ISO9001 Certified CNC Milling Parts，100% Inspection CNC Machined Parts
Description
High-Speed CNC Turned Graphite Electrode
CNC Turning Parts Specifications
Product Name CNC Turning Parts
Material Available Aluminum
Processing CNC Turning
Tolerance ±0.002~0.005mm
Drawing Accepted IGES(igs), STEP(stp), SolidWorks (sodprt), PRT, AutoCad, or Samples
Inspection CMM, Projector, Height Gauge, etc.
Lead Time 7~35 working days
Quality Assurance ISO9001:2015, SGS, RoHs
Payment Term MoneyGram, Western Union, T/T, D/P, D/A, L/C
Price According to your drawing or requirements
Packaging and Delivery
Packaging Bubble and Carton or Customization
Port Shenzhen
High-Speed CNC Turned Graphite Electrode with ±0.002~0.005mm Tolerance and ISO9001 Certified Precision Machined Components
CNC Turning Parts Characteristics

CNC turning parts feature high precision and excellent consistency, and are capable of machining metal or non-metal components with diverse complex structures such as shafts and discs. Controlled precisely by pre-set programs, the machining process enables one-time forming of intricate details like complex threads, chamfers and grooves, making these parts well-suited for the stringent application requirements in machinery manufacturing, automotive, aerospace and other industries.

Secondary Operations & Finishing
Value-Added Services
Operation Equipment Used Capability/Specification
CNC Milling 3/4/5-axis mills Cross-holes, flats, keyways, complex features
Drilling/Tapping CNC drill units Deep hole (up to 10× diameter), micro-drilling (Ø0.3mm+)
Grinding Cylindrical grinders ID/OD grinding, surface grinding
Heat Treatment Vacuum furnaces Hardening, tempering, stress relieving, annealing
Welding TIG, laser welders Precision welding for assemblies
Assembly Cleanroom facilities Press fits, adhesive bonding, mechanical fastening
Surface Finishes
Finish Type Process Typical Ra Value Characteristics
As-Machined CNC turned 0.8-3.2μm Cost-effective, tool marks visible
Polished Mechanical polishing 0.1-0.4μm Reflective, smooth, cosmetic quality
Anodized Type II/III anodizing 0.4-1.6μm Decorative, corrosion resistant (Al)
Plated Electroplating Varies Chrome, nickel, zinc, tin coatings
Passivated Chemical treatment Base material finish Corrosion resistance (stainless)
Painted/Powder Coated Spray application Varies Color options, additional protection
Black Oxide Chemical conversion Base material finish Mild corrosion resistance, appearance
Quality Assurance & Inspection
Inspection Equipment
  • Multi-Sensor CMMs: 3D measurement with 0.001mm accuracy
  • Optical Comparators: Profile projection with 20× to 100× magnification
  • Surface Roughness Testers: Portable and benchtop Ra/Rz measurement
  • Hardness Testers: Rockwell, Brinell, Vickers, and micro-hardness
  • Thread Gauges: Complete sets to ISO/ANSI standards
  • Digital Calipers/Micrometers: 0.001mm resolution, calibrated regularly
  • Roundness Testers: Concentricity and cylindricity measurement
  • Force Measurement: Torque testing, spring constant verification
Quality Certifications & Processes
  • ISO 9001:2015 certified quality management system
  • First Article Inspection (FAIR): AS9102/PPAP documentation available
  • Statistical Process Control (SPC): Real-time monitoring of critical dimensions
  • Material Traceability: Mill test certificates, heat/lot number tracking
  • Calibration Program: All inspection equipment calibrated to NIST standards
  • Document Control: Revision-controlled drawings and specifications
High-Speed CNC Turned Graphite Electrode with ±0.002~0.005mm Tolerance and ISO9001 Certified Precision Machined Components High-Speed CNC Turned Graphite Electrode with ±0.002~0.005mm Tolerance and ISO9001 Certified Precision Machined Components High-Speed CNC Turned Graphite Electrode with ±0.002~0.005mm Tolerance and ISO9001 Certified Precision Machined Components

Customization & Service Workflow

Design Support Services

DFM Analysis: Design for manufacturability review within 24 hours of drawing submission

Engineering Collaboration: Co-development with customer engineering teams

Rapid Prototyping: 3D printing (SLA, SLS, MJF) available for concept validation

Order Process

Quotation Request: Submit drawings (DXF, DWG, PDF) or 3D models (STEP, IGES, SLDPRT)

Technical Review: Engineering assessment of materials, tolerances, and finishing

Commercial Proposal: Detailed quotation including unit pricing, tooling costs, lead time

Prototype Approval: Sample production with inspection report submission

Production Release: Scheduled manufacturing with milestone updates

Quality Verification: Final inspection report prior to shipping

Delivery & Support: Tracking information and post-sales technical assistance

Competitive Advantages

Technical Expertise

12+ years average experience among engineering staff

Dedicated project management for each account

Continuous process optimization through Six Sigma methodologies

Supply Chain Reliability

Long-term partnerships with certified material suppliers

Risk mitigation through multi-source material procurement

Inventory management programs for repeat components

Global Compliance

ISO 9001:2015 certified quality management system

Conflict-free mineral sourcing documentation

REACH and RoHS compliance for applicable materials
