Specifications
Brand Name :
Mingrui
Model Number :
XF-081
Certification :
ISO9001, FDA, NSF , WARS
Place of Origin :
China
MOQ :
1 pieces
Price :
negotiable
Payment Terms :
L/C, T/T, Western Union, , D/P, D/A
Supply Ability :
8000 pieces month
Delivery Time :
15 working days after the order confirmed
Packaging Details :
intertional carton box
Name :
Advanced Ceramics Machinable Zirconia Ceramic Guide Block for Solar Photovoltaic Systems
Application :
Solar Photovoltaic Systems
Material :
Zirconia
Accuracy :
0.001
Size :
Super high precision
Shipping :
DHL EMS UPS FEDEX TNT
Type :
Structure Ceramic
OEM :
yes and welcome
Description


Advanced Ceramics Machinable Zirconia Ceramic Guide Block for Solar Photovoltaic Systems


Ceramic guides have been used in various applications within the saw mill industry for the past 15 years. Our Delta 14 inch, Delta 12 & 16 inch, Import, and Craftsman Old Style Ceramic Guideblock products all are suitable for use with any blade width.
Made of virtually indestructible ceramic, the ultra-smooth surface, low friction thrust bearings and guide block products provide excellent support to bandsaw blades. They run cooler, provide truer tracking, and make the blades run much smoother and quieter.

Why You Need Mingrui Ceramic Guideblocks

Our guide blocks reduce friction and can reduce pitch build-up on the blade. They work with blades 1/4″ wide and up. Keep the blocks clear of the blade teeth. Our import set will fit Jet and General 14″ saws, and most Delta 14″ clones. All block sets come as a set of 4 that includes both upper and lower guides.

The specification of the alumina ceramic plates
1. Material : 96% alumina, 99% alumina, 99.5% alumina, zirconia, silicon nitride, silicon carbide optional
2. Dimensional capability Side length max. 500mm x 600mm, Thickness can be range from 0.15mm to 30mm
3. Surface treatment: natural surface, lapping, diamond-like polishing, metallization, glazed
4. We have many selections of al2o3 ceramic plates, refer to the checklist of standard size in different purity.

S/N Material Length
(mm)		 Width
(mm)		 Thickness
(mm)		 S/N Material Length
(mm)		 Width
(mm)		 Thickness
(mm)
1 96%
alumina		 114 114 0.385 25 99%
alumina		 49 42 3
2 190 138 0.5 26 100 25 3
3 280 240 0.6 27 105 95 5
4 190 138 0.75 28 140 140 5
5 142 132 0.8 29 192 40 6
6 130 109 1 30 150 140 8
7 114 114 1 31 300 180 8
8 230 190 1 32 165 165 8
9 280 240 1 33 100 100 10
10 395 83 1 34 280 240 10
11 92 19 1.9 35 105 50 12
12 51 4 2 36 300 200 10
13 45 14 2.5 37 280 240 15
14 160 120 3 38 300 200 15
15 160 120 4 39 530 250 15
16 160 120 5 40 300 200 20
17 99%
alumina		 10 25 2 41 400 400 25
18 10 30 2 42 99.5% alumina 150 126 2
19 24.8 24.8 2.5 43 156 150 2
20 24 24 3 44 180 150 2
21 30 20 3 45 150 70 4
22 30 25 3 46 150 150 4
23 36 30 3 47 156 150 4
24 36 36 3 48 180 150 4

Remark:
All the above big size ceramic sheets can be cut to specific dimensions per customers' requirement.


Application

Advanced Ceramics Machinable Ceramic Block for Solar Photovoltaic Systems

Properties of Alumina and Zirconia Ceramic :
Properties Units 95 Alumina 99 Alumina ZrO2
Density g / cm³ 3.65 3.92 5.95-6.0g/cm³
Water absorption % 0 0 0
Coefficient of thermal expansion 10-6/K 7.9 8.5 10.5
Modulus of Elasticity Young's Mod GPa 280 340 210
Poisson's ratio / 0.21 0.22 0.3
HV Hardness HV MPa 1400 1650 1300-1365
Flexural Strength @ room temperature MPa 280 310 950
Flexural Strength @700°C MPa 220 230 210
Compressive Strength @ room temperature MPa 2000 2200 2000
Fracture Toughness MPa *m 1/2 3.8 4.2 10
Heat conductivity @ room temperature W/ m*k 18-25 26-30 2-2.2
Electrical Resistivity @ room temperature Ω*mm2 /m >1015 >1016 >1015
Max use temperature °C 1500 1750 1050
Resistance to acid alkaline / high high high
Dielectric Constant / 9.5 9.8 26
Dielectric Strength KV/mm 16 22 /
Thermol Shock Resistance △ T ( °C ) 220 180-200 280-350
Tensile Strength @ 25 °C MPa 200 248 252

Company Introduction:


We ( Dongguan Mingrui Ceramic Technology Co., Ltd ) are a professional manufacturer specialized
in R&D, manufacturing and selling customized all kinds of high precision zirconia and alumina ceramic parts . Our main products include ceramic rod , ceramic tube, ceramic plunger, ceramic valve, ceramic plate, ceramic shaft and bearing , ceramic nozzle etc , which are mainly used in industrial fields of Machinery, Petrochemical oil and gas, Valves, Automotive, Food Processing, Fluid Handling, Process Control, Thermal Processing, Aerospace, Defense, Eletronic and Electrical, Textile, Mechanical, Engineering, Mineral Processing, etc.
We have a full service include mold design and development , ceramic forming , precision machining
and precision detection technology. We have achieved great successes in particular requirements
which is based on cooperating with Tsinghua University and getting rich experience by our professional technical engineer teams . Our factory have an unique technical called mirror polishing which improve
our products more smooth , bright than other competitors.


FAQ :

1. Are you a manufacturer ?
Yes we are a ceramic manufacturer . We proceed with the whole process start from Powder material to forming , sintering , machining, marking , inspection , packing , we do the whole process .


2. What kind of industry ceramics do you have ?
We specialized in 95% 97% 99% alumina ceramic and zirconia ceramic parts .

3. What kind of molding method do can you supply ?
Dry Pressing , isostatic pressing , grouting , hot-chamber die casting , tape casting , injection molding, etc, injection molding and isostatic molding is the most commonly used.

4.What stabilizer do you use when processing ?
Yttria stabilizer is the most commonly used in our industrial ceramic parts.

5.Can you produce free samples for me ?
Yes usually , we can produce free samples for you but it is up to the product complexity .

6.What terms can you accept for payment ?
T/T, L/C , Western union , and Paypal is welcome , but paypal and western union only for small -sum payment.
