VMC-1580HL Vertical Machining Center | BT40 High Precision CNC Milling Machine
VMC-1580HL Vertical Machining Center | BT40 High Precision CNC Milling Machine
Specifications
Positioning Accuracy :
±0.005 Mm
X-Axis Travel :
500 Mm
Machine Weight :
1800 Kg
Delivery Time :
30-45DAYS
Payment Terms :
T/T
Spindle Motor Power :
7.5 KW
Price :
USD10000
Tool Magazine Capacity :
24 Tools
Place of Origin :
JIANGSU
Brand Name :
GUSS
Certification :
CE
Power Supply :
3 Phase, 380V, 50Hz
Rapid Traverse Rate :
30 M/min
Model Number :
VMC-1860HL
Supply Ability :
10 PCS/MONTH
Repeatability :
±0.003 Mm
MOQ :
1
Description

VMC-1580HL Vertical Machining Center

Product Features

  1. VMC-1580HL vertical machining center adopts high-rigidity integral cast iron bed, column and spindle box. Optimized via finite element analysis and fully annealed to eliminate internal stress, the entire structure resists deformation and maintains long-term stable precision and high strength for heavy-duty machining.
  2. Designed with a wide base and triangular box-type column, this CNC machine features full heavy-load support and symmetrical body structure. It ensures stable load balance, low vibration and low noise during high-speed and heavy cutting operations.
  3. Reinforced spindle box provides firm spindle support. X/Y/Z axes adopt high-precision C3 pre-tensioned ball screws and roller linear guides, delivering low friction, quiet operation and outstanding circular accuracy. All axes reach 24m/min rapid traverse for efficient high-speed machining.
  4. Equipped with three-axis absolute servo motors, the machine requires no origin reset, greatly improving working efficiency. Motor and screw direct connection via precision couplings eliminates transmission backlash, while limit-switch-free design lowers failure rates and enhances stability.
  5. Featuring a 10000rpm high-precision belt spindle with labyrinth seal and standard air curtain protection, the spindle effectively resists cutting fluid intrusion and extends service life. High-torque spindle configuration and durable four-jaw pull claw guarantee strong cutting force and stable tool clamping.
  6. The 200L large-capacity water tank with multi-stage filtration ensures smooth chip removal and clean machining. Side-mounted electrical cabinet saves floor space, making this high-precision BT40 vertical machining center perfect for mold manufacturing and heavy metal cutting applications.

Technical Specifications

Item Unit VMC-1580HL
3-Axis Travel (X/Y/Z) mm 1500/800/700
Distance from Spindle Nose to Worktable Surface mm 150-850
Spindle Taper - BT40
Spindle Motor Power (Rated-Max) Kw 11-15
Spindle Motor Torque (Rated-Max) N.m 52.5-70.0
Tool Magazine Type - Arm Type
Number of Tools pcs 24
Max Tool Diameter (Full Magazine / Adjacent Empty) mm 80 / 150
Max Tool Length mm 300
Max Tool Weight Kg 8
Max Spindle Speed rpm 10000
X/Y/Z Axis Motor Power Kw 4.5/4.5/4.5
X/Y/Z Axis Motor Torque N.m 37.2/37.2/37.2
Worktable Dimensions mm 1700×800
Max Worktable Load Kg 1500
T-Slot Specification mm 5-18×150
X/Y/Z Axis Rapid Traverse Speed m/min 24/24/24
Cutting Feed Speed mm/min 1-10000
Positioning Accuracy mm ±0.006
Repeat Positioning Accuracy mm ±0.004
CNC System - Mitsubishi M80
Machine Weight Kg 15800
Power Demand KVA 30
Water Tank Capacity L 200
Air Pressure Requirement kg/cm² 6.0
Machine Height mm 3100
Floor Dimension (With Chain Chip Conveyor) mm 4800×3600 (5050×3000)

All major purchased parts adopt world-renowned brand components to ensure stable machine performance and long service life:

  • Spindle Brand: Taiwan Okada / Jianchun / Ruiying
  • Linear Guide Rail: PMI / HIWIN
  • Ball Screw: PMI / HIWIN
  • Disc Tool Magazine: Taiwan Detai / Okada
  • Control System: Japan Mitsubishi
  • Spindle Motor: Japan Mitsubishi
  • Servo Motor: Japan Mitsubishi
