Specifications
Brand Name :
APBWR
Model Number :
BWR130B-1RF
Certification :
ISO9001
Place of Origin :
CHINA
MOQ :
1 UNIT
Price :
$5000-50000
Payment Terms :
L/C,T/T
Supply Ability :
1000+ /year
Delivery Time :
14-21DAYS
Packaging Details :
Pallets or wooden crates as per customer's requirements.
Product name :
Automatic Light Duty Metal Wire Mesh Loom
Key word :
Light Duty Metal Wire Mesh Loom
Place of origin :
China
Mesh Width :
1300MM
Harness System :
Positive (Overhead)
Web Removal Method / Doffing Method :
Continuous Web Removal or Direct Winding
Beating-Up Frequency :
Max. 120 r/h
Motor Power :
2.2kw
Description

Automatic Light Duty Wire Mesh Weaving Machine Optimal Efficiency 1300B


1.Light Duty Wire Mesh Introduction


The SG100 series CNC metal wire mesh weaving machine is mainly suitable for weaving high - mesh wire meshes. It has the characteristics of low noise, diverse patterns, and convenient maintenance.

2.Light Duty Metal Wire Mesh Loom Main Technical Parameters

  • Model: BWR1300B
  • Wire diameter range: 0.03 - 0.2mm
  • Weaving density: 30 - 500 meshes/inch for plain - woven square holes; 30-635 meshes/inch for twill weaving.
  • Standard width: Options such as 1m, 1.3m, 1.6m and 2.7m are available. Special widths can be customized as required.
  • Rotating speed: 80 - 120 rpm. The spindle speed is adjusted by a frequency converter, and the actual speed depends on the weaving width and specification.
  • Shedding form: Three shedding structures are optional: cam - guided dobby mechanism, electronic rotating multi - arm machine, and servo multi - arm machine. Aluminum alloy heald frames: If an electronic rotating multi - arm machine is selected, up to 20 heald frames can be used.
  • Weft insertion mechanism: Servo motor - controlled CNC unidirectional weft insertion or CNC bidirectional weft insertion, with full carbon fiber rapier tape.
  • Clamping method: One - time clamping.
  • Warp feeding/mesh winding: CNC warp feeding (with real - time display and automatic adjustment of warp tension); CNC mesh winding (three - roll mesh winding).
  • Weaving wire materials: Metal and non - metal wire meshes made of various materials such as stainless steel, iron, copper, brass, phosphor bronze, aluminum, platinum, polyester, and plastic.
  • Weaving method: Plain weave, twill weave, dense weave, three - heald weave, five - heald weave, reverse differential dense weave, satin weave, variable weft density, etc. can be performed as required. If a multi - arm machine is selected, various patterns can be woven.
  • Basic tension: 15000 N/m
