Specifications
Place of Origin :
Guangdong, China
Brand Name :
RUI-HE
MOQ :
2
Price :
$8-9
Shore Hardness :
50 A
Viscosity :
14 Pa.s
Density :
0.99 g/cm3
Light Transmittance :
94%
Tensile Strength :
4 MPa
Elongation :
150%
Tear Strength :
9 KN/m
Tensile Set :
≤3.2%
Line Shrinkage :
≤2.5%
Mixing Ratio :
1:1
Curing Temperature :
150°C
Curing Time :
5 min
Resilience :
35%
Material Type :
100% Silicone
Packaging Size :
20kg or 200kg
Description
Product Description
50 Shore A Transparent LSR Silicone Rubber for Glass Nose Pads


Optical Silicone Rubber

RH5350-50KSA/B is platinum cured silicone rubber for silicone products.

The silicone rubber is a two-component liquid silicone rubber for injection moulding processes.

RH5350-50KSA/B can be suitable for the production of a variety of transparent glass-like products,such as LED secondary lenses,glasses nose pads,etc.
Details images

Typical sulphidation conditions:
A:B=1:1,150C/5min

Molding process:
A/B 1:1 Heating injection molding

Packing
A:B, 20KG/bucket OR 200KG/bucket

Storge:
Please sealed and keep at room temperature

Note:
This product can not contact with N,P,S compounds,so as not to make platinum catalyst poisoning.
50 Shore A Transparent LSR Silicone Rubber for Glass Nose Pads
50 Shore A Transparent LSR Silicone Rubber for Glass Nose Pads
Features
1.Simple operation——without additional curing agent
2.Fast curing at low temperature (120°C--140°C)
3.Environment-friendly——do not release the unpleasant odor and harmful gases
4.Excellent anti-yellowing property
5.Stable product size

Typical Properties
RH5350-50KSA/B®
Unit
Part - A
Part - B
Appearance
/
transparent
transparent
Viscosity
Pa.s
14
Shore A Hardness
A
50
Density
g/cm3
0.99
Light Transmittance
/
94
Resilience
%
35
Tensile Strength
MPa
4
Elongation
%
150
Tear Strength
KN / m
9
Tensile Set
%
≤3.2
Line shrinkage
%
≤2.5

These figures are for reference only, please contact us for details.
The mixing ratio of components A: B = 1: 1.
Vulcanization: 150 °C / 5 min

Packing & Delivery
50 Shore A Transparent LSR Silicone Rubber for Glass Nose Pads

Packaging & Storage

Available in 20kg pails or 200kg drums.
Store in a cool, dry place out of direct sunlight, use it within 12 months from the day of manufacture.

50 Shore A Transparent LSR Silicone Rubber for Glass Nose Pads


This product cannot be contacted with compounds containing N, P, S to avoid affecting the catalytic effect of platinum.

50 Shore A Transparent LSR Silicone Rubber for Glass Nose Pads
Certifications


RH5350-50KSA/B® Liquid silicone rubber obtained the following test certificate:

FDA 21, CFR 177. 2600 ,RoHS, BfR, , REACH, PAHS, UL, ISO9001:2015, etc.




50 Shore A Transparent LSR Silicone Rubber for Glass Nose Pads
Application
50 Shore A Transparent LSR Silicone Rubber for Glass Nose Pads

Applied range


* Square, kink free tubing for furnace pressure switches
* Sound and vibration dampening in automotive drive shaft applications
* Shaft sealing rings
* Silicone O rings
* Window and door seals
* Sealing GasketsOven door gaskets
* Wire and cable jacketing
* Electrical Safety Stinger Covers
* Conductive profiled silicone seals

50 Shore A Transparent LSR Silicone Rubber for Glass Nose Pads
50 Shore A Transparent LSR Silicone Rubber for Glass Nose Pads
Our Company

Guangzhou Rui-He New Material Scientific Co., Ltd


Established in 2004, specializes in search, development, production, and distribution of environmentally-friendly silicone materials.


Our headquarters is located in Huadu district, Guangzhou, China. Our products are widely used in all kinds of industries, such as medical, electronics, telecommunication, aeronautics, astronautics, automobile, textile, mechanics, sports and daily necessities.


Through the 15 years, we are now recognized as the famous leading silicone rubber manufacturer.
Rui-He has more than 1,000 types of silicone rubber. Annual output we produce 12000 tones of silicone rubber.


We are generally sorted as LSR liquid silicone rubber, solid silicone rubber, HTV silicone rubber, RTV-2 molding silicone rubber, precipitation silicone rubber, injection molding silicone rubber, flame retardant silicone rubber, high temperature silicone rubber, electrical insulating silicone rubber, potting silicone rubber, medical silicone rubber, and the silicone rubber for cable accessories, baby's products, kitchenware and diving tools, etc.

50 Shore A Transparent LSR Silicone Rubber for Glass Nose Pads
50 Shore A Transparent LSR Silicone Rubber for Glass Nose Pads
50 Shore A Transparent LSR Silicone Rubber for Glass Nose Pads
50 Shore A Transparent LSR Silicone Rubber for Glass Nose Pads

Each batch of silicone rubber must be tested by our safe quality examination system.

50 Shore A Transparent LSR Silicone Rubber for Glass Nose Pads

Test items: physical property testing and chemical property testing.

50 Shore A Transparent LSR Silicone Rubber for Glass Nose Pads

Testing equipment in line with international quality standards.

FAQ


1. What's silicone products you are making?

--liquid silicone rubber, silicone rubber, silicone oil; Platinum agent:

-- According to different silicone molds, our silicone has different viscosity, and cause different hardness,

density to meet the requests from client.


2. Do you offer free sample to client?

--Yes, we can provide the sample for test.


3. How about the quality control in your factory?

--We have professional QC team.

--Each batch of silicone rubber must be tested by our safe quality examination system.


4. How to remove the bubbles during my mould making?

--After mixing liquid silicone with curing agent, please put the material into vacuum machine to take off the bubbles.


5. How to get good silicone mould to use longer time?

--The best way is:

1, Please choose the right liquid silicone according to your products.

2, Don't use any silicone oil in mold making, because it can make the silicone mould become too soft to use.

3, Silicone mould can be used longer after the whole silicone mould fully cured, so it's better to wait 2 hours after mould finished.


6. Why silicone rubber add curing agent after mixing a lot of bubbles?

--This is normal physical phenomena. The liquid will produce a large number of bubbles in the mixing time, so, it must pass through the vacuum exhaust bubble treatment.
