Specifications
Description
FAW J6F 6m³ Compactor Truck – Smart Waste Management Solution
Introducing the HUBEI CLW FAW J6F 6m³ Special Vehicle - your ultimate partner in urban cleanliness. Designed for efficiency and built to last, this compact garbage compactor truck transforms the way cities handle waste.
Overview
Say goodbye to inefficient waste transport. Our 6m³ compactor truck, mounted on the famous FAW J6F chassis, features a powerful compression mechanism that packs more waste into every load. Engineered by Hubei CLW Special Vehicle Co., Ltd., it's the perfect blend of power, capacity, and environmental responsibility.
Key Features
  • FAW J6F Chassis: Known for its stability, comfort, and low fuel consumption
  • 6m³ Volume: Compact size for narrow streets, yet spacious enough for heavy-duty tasks
  • Powerful Compression: Reduces waste volume by up to 70%, saving time and fuel on trips
  • 100% Anti-Leakage: Advanced sealing technology ensures no secondary pollution to the roads
  • Easy to Operate: Simple hydraulic controls allow for quick loading and unloading cycles
  • Customizable Options: Available with various bin loading mechanisms (e.g., rear dustbin loading)
Applications
  • Municipal Street Cleaning
  • Residential Area Waste Collection
  • Hotel & Resort Waste Management
  • Small to Medium-Sized Factory Waste Disposal
Product Specifications
Technical Specifications
Chassis Model FAW J6F
Overall Dimensions (L*W*H) 6,500 * 2,100 * 2,500 mm (approx.)
Garbage Bin Capacity 6 m³
Max Compression Ratio 1:0.6 - 1:0.8 (depending on waste type)
Loading Cycle Time ≤ 18 seconds
Unloading Cycle Time ≤ 45 seconds
Max Payload 3,000 - 4,000 kg (approx.)
GVWR (Gross Vehicle Weight Rating) 7,300 kg (approx.)
Chassis & Drivetrain
Engine Brand FAW / Deutz (China IV/V/VI Emission Standard)
Engine Power 130 HP - 160 HP
Transmission Manual / Automatic (Optional)
Drive Type 4*2
Cab Capacity 3 Persons
Steering Power Steering
Brake System Air Brake / Oil Brake (Optional)
Tire Size 7.00R16 / 7.50R16
Compactor Body & Hydraulic System
Bin Material High-Strength Wear-Resistant Steel (Q345 / T700)
Bin Thickness Side: 3 mm / Bottom: 4 mm
Sealing Type Fully Sealed with Rubber Seal Strip
Hydraulic System Pressure 16 MPa
Hydraulic Oil Tank Capacity 80 L - 100 L
Control System Manual Valve + PLC Remote Control (Optional)
Loading & Unloading Mechanism
Loading Method Rear Loading (Compatible with standard dustbins)
Bin Lifting Capacity 240 L / 660 L Standard Dustbins
Dumping Angle ≥ 45°
Tailgate Opening Method Hydraulic Up-Down / Side Swing (Optional)
